High Power Diode Laser Source with Wavelength Coupling Technology

Abstract:

Laser diode has incited particular interest as photoelectric conversion efficiency, output power and lifetime for a variety of applications in industry processing. The single laser diode optical power has not satisfied for the actual requirements. It demands to couple several diode laser beams into one beam to output directly or by an optical fiber to improve the brightness, and it becomes the central issue to adopt the appropriate beam coupling technology which would offer high quality and high efficiency. In order to output high power, we utilized wavelength coupling technology to couple two laser beam of different wavelength together with beam splitter cube (BSC), the key technology and the principle of wavelength coupling is indicated and analyzed in this paper .Using 808nm and 980nm laser diode realize wavelength coupling with high output power, the efficiency more than 80% and spot size can be achieved after focusing to the beam size of 3×3mm².

• Periodical: Advanced Materials Research (Volume 710)
• Pages: 442-446
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.710.442
• Online since: June 2013
• Authors: Yuan Yuan Gu, Guo Xing Wu, Hui Lu, Yan Cui
• Keywords: Diode Laser, Incoherent Beam Coupling, Laser Technique, Wavelength Coupling

References

[1] Ivan P. Kaminow, Tingye Li, Alan E. Willner. in: Optical Fiber Telecommunications V A: Components and Subsystems. Vol 1, chapter 5 by Ch. Harder, 2008, ISBN: 978-0-12-374171-4

[2] Gapontsev V, Moshegov N., Trubenko P., Komissarov A., Berishev I., in: High-Brightness 9XX-nm Pumps with Wavelength Stabilization, Proc. SPIE 7583 (2010)

DOI: 10.1117/12.905982

[3] Niu J., Xu J. in: Coupling efficiency of laser beam to multimode fiber, Opt. Commun. 274, 315-319 (2007).

DOI: 10.1016/j.optcom.2007.02.027

[4] Qiu X., Dai Y., Au M., Guo J., Wonga V., Rossin V., Venables D., Skidmore J., Zucker E., in: A High Power, High-Brightness Multi-Single-Emitter Laser Pump Platform, Proc. SPIE 7198 (2009).

DOI: 10.1117/12.809671

[5] Paul Wolf , Bernd Köhler, Karsten Rotter, Susanne Hertsch, Heiko Kissel, Jens Biesenbach, in: High-power, high-brightness and low-weight fiber coupled diode laser device, Proc. SPIE 7918(2011).

DOI: 10.1117/12.875147

[6] Purnawirman, P. B. Phua, in: Coherent Polarization Locking of Multimode Beams in a Diode Bar, Proc. of SPIE Vol. 7918(2011).

DOI: 10.1117/12.873692

[7] Christoph Ullman, Bad Honnef, Volker Krause, Hohr-Grenzhausen, United States Patent, US6771686B1.
