Two Methods of Improving the Focus Survey Precision Based on CCD Camera

Abstract:

The principium of measuring focus of aerial camera and the location of the actual image plane with CCD camera are introduced, and the methods to improve survey precision are described. The image is received by area CCD camera. The accuracy of orientation of the imaging central line is improved by means of fit the curve method or by center of gravity method. Therefore, the distance between imaging central lines is refinedly calculated. The experimented turn out that the two methods on measuring focus of aerial camera have high precision, and the survey errors are in accordance with the theoretical ones (0.12%). The two methods on deterministic result of the location of the actual image plane are identical, with their precision reaching 100%.

• Periodical: Advanced Materials Research (Volume 710)
• Pages: 438-441
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.710.438
• Online since: June 2013
• Authors: Mei Zhao, Yu Fang Sha, Fei Guo, Ying Zhao, Jun Xie, Wei Han
• Keywords: CCD Camera, Centre of Gravity Method, Fit the Curve Method, Focus, Survey Precision

References

[1] Yu Zhang: Journal of Optoelectronics·Laser, Vol.14(10) (2003), p.1118. In Chinese.

[2] Xingsheng Xie, Shanchang Tao and Xiuji Zhou: Chinese Science Bulletin, Vol.44(1) (1999), p.97. In Chinese.

[3] Mei Zhao, Jiujun Zhang and Maiyu Zhou: Journal of Optoelectronics·Laser, Vol.16(2) (2005), p.189. In Chinese.

[4] Datu Su, Liping Zhao and Dingguo Sha. "Optical Testing Technology" Press, 1996.19-20.

[5] Chaohui Li, Haipeng Kuang: Chinese Journal of Scientific Instrument, Vol.23(2) (2002), p.166. In Chinese.

[6] Haipeng Kuang, Linpei Zhai: Optical Technique, Vol.30(1) (2004), p.122. In Chinese.

[7] Yuliang Zhao, Kaiduan Li: Optical Technique, Vol.28(3) (2002), p.204. In Chinese.

[8] Xin Gao, Ying Wang and Huiming Huang: Optical Technique, Vol.28(4) (2002), p.376. In Chinese.
