Tool Wear Monitoring Using Microphone Signals and Recurrence Quantification Analysis when Drilling Composites

Abstract:

The quality of the hole produced during the drilling of composite materials is one of the controlling factors for the resulting joint strength and integrity of the structural component. Quality of the hole depends on the condition of the cutting tool. Continuous cutting tool condition monitoring method is vital to accomplish the desired hole quality. To address this concern, an online tool condition monitoring technique using a simple audio microphone as a sensor is developed and Recurrence Quantification Analysis (RQA) methodology was used as a signal analysis tool to predict the tool condition in terms of flank wear. A series of experimental drilling operation was carried out on uni-directional carbon fiber reinforced plastic (CFRP) composite. It was found that the amplitude of the microphone signal decreases with the increase of the tool flank wear. In addition, from the selected eight RQA output variables, six of them show an increasing trend with the increase of the measured flank wear, whereas, two of them show a decreasing trend with the increase of tool wear. The same trend has been observed in both set of experiments. These results demonstrate that, this novel approach is an effective and economical online tool condition monitoring method.

• Periodical: Advanced Materials Research (Volume 711)
• Pages: 239-244
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.711.239
• Online since: June 2013
• Authors: Eshetu D. Eneyew, M. Ramulu
• Keywords: Carbon Fiber Reinforced Polymer/Plastic (CFRP), Composite, Drilling, Machining, Quality, Tool Condition, Wear

References

[1] M. Ramulu, P. Young and H. Kao, " Drilling of Graphite/Bismaleimide Composite Material" Journal of Materials Engineering and Performance, Vol.8, No.3, 1999, pp.330-338

DOI: 10.1361/105994999770346882

[2] M. Ramulu, T. Branson, and Dae-Wook Kim, "An Experimental Study On The Drilling Of Graphite/Bismaleimide Composite and Titanium Stacks" Composite Structures, Vol.54, No.1, 2001, pp.67-77

DOI: 10.1016/s0263-8223(01)00071-x

[3] D.H. Wang, C.W. Wern, M. Ramulu, and E. Rogers. "Cutting Edge Wear of Tungsten Carbide Tool in Continuous and Interrupted Cutting of a Polymer Composite," Materials and Manufacturing Processes, Vol. 10, No. 3, 1995, pp.493-50

DOI: 10.1080/10426919508935040

[4] T. I. El-Wardany, D. Gao, and M. A. Elbestawi, " Tool Condition Monitoring in drilling Using Vibration Signature Analysis", International Journal ofMachine Tools and Manufacture, Vol. 36, No. 6, p.687 – 711, 1996.

DOI: 10.1016/0890-6955(95)00058-5

[5] Issam Abu-Mahfouz, "Drilling Wear Detection and Classification using Vibration Signals and Artificial Neural Network", International Journal ofMachine Tools and Manufacture, Vol. 43, p.707 – 720, 2003.

DOI: 10.1016/s0890-6955(03)00023-3

[6] Qiao Sun, Ying Tang, Wei Yang Lu, and Yuan Ji, " Feature Extraction with Discrete Wavelet Transform for Drill Wear Monitoring, " Journal of Vibration and Control, Vol. 11, No. 11, p.1375 – 1396, 2005.

DOI: 10.1177/1077546305058262

[7] A. Velayudham, R. Krishnamurthy, T. Soundarapandian, "Acoustic Emission Based Drill Condition Monitoring during Drilling of Glass/Phenolic Polymeric Composite using Wavelet Packet Transform", Material science and Engineering A, Vol. 412, p.141 – 145, 2005.

DOI: 10.1016/j.msea.2005.08.036

[8] A. Chukwujekwu Okafor and Scott. R. Bridsong, " Monitoring Drilling of Advanced Composites, Drill Wear and Exit Delamination using Wave – Based Acoustic emission", SPIE, Vol. 3589, pp.115-124, (1999)

DOI: 10.1117/12.339964

[9] Karali Patra, "Acoustic Emission based Tool Condition Monitoring System in Drilling", Proceedings of the World Congress on Engineering, Vol. III, (2011)

[10] J. –P. Eckmann, S. Oliffson Kamphorst, and D. Ruelle, "Recurrence Plots of Dynamical Systems", Euro physics Letters, Vol. 4 (9), p.973 – 977, 1987.

DOI: 10.1209/0295-5075/4/9/004

[11] Joseph P. Zbilut and Charles L. Webber Jr., " Recurrence Quantification Analysis", Wiley Encyclopedia of Biomedical Engineering, (2006)

DOI: 10.1002/9780471740360.ebs1355

[12] Jorge Belaire-Franch and Dulce Contreras, "Recurrence Plots in Nonlinear Time Series Analysis: Free Software" Dept. of Economic Analysis, University of Valencis.

DOI: 10.18637/jss.v007.i09
