BIM-Based Integrated Design Software for the Steel Structure of Industrial Plant

Abstract:

The developed BIM-based integrated design software system is composed of two seamlessly integrated modules: structure calculation module and post-process module, the interface between the modules is clear. Using object oriented programming technology, a series of intelligent solid classes are abstracted to describe parts with deferent geometric information, structure properties and design requirements in real structure. Objects which are instances of these hierarchical C++ classes and logical links between them were integrated into the AutoCAD drawing database to construct a three-dimensional model. Several key functions including parametric shortcut modeling, frames analysis and member checking, three-dimensional solid construction, node design and editing, and drawing are implemented. IFC interface and the interface with common software are also implemented.

• Periodical: Advanced Materials Research (Volumes 712-715)
• Pages: 1185-1188
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.712-715.1185
• Online since: June 2013
• Authors: Zhi Guo Chang*
• Keywords: Building Information Modeling (BIM), CAD, IFC, ObjectARX, Steel Industrial Plant Structure

References

[1] Paola Sanguinetti etc.Advanced Engineering Informatics, Vol. 26, Issue 2, April 2012, pp.317-333

[2] Rory Clune, etc., Computers and Structures, Vol. 100-101, June 2012, pp.1-17

[3] Sungyol Song, etc.,, Computers in Industry, Vol. 63, Issue 9, December 2012, pp.895-912

[4] Dapeng Wang, etc.,,, Computer Aided Engineering, 2001, Vol. 10(4): pp.55-58(in Chinese)

[5] National Standard of the People's Republic of China, GB50017-2003 Code for design of steel structures, Beijing, China Planning Press, 2003(in Chinese)

[6] Steel Design Manual (third edition) [M], Beijing: China Building Industry Press, 2003(in Chinese)
