The Electric Spindle Built-in Motor Thermal Equilibrium Active Temperature Control Model

Abstract:

Based on the structure characteristics of electric spindle built-in motor and numerical heat transfer theory,electric spindle built-in motor physical heat conduction model was given and a mathematical temperature control model for the electric spindle built-in motor was established. According to the mathematical temperature control model, controllable factors for the heat balance was determined. By electric spindle own screw channels, using this mathematical temperature control model to adjust the flow speed and fluid medium temperature, the built-in motor quickly reached heat balance and maintained temperature field stability in the electric spindle start-stop and using process. Then the theoretical calculations and simulation on the electric spindle built-in motor was conducted.This model is designed to enhance high-speed precision spindle machining accuracy and the use of performance.Nomenclature:

• Periodical: Advanced Materials Research (Volume 716)
• Pages: 727-732
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.716.727
• Online since: July 2013
• Authors: Li Gang Cai, Xu Zhuo, Yong Sheng Zhao, Zhi Feng Liu
• Keywords: Built-in Motor, Electric Spindle, Simulation Analysis, Thermal Equilibrium Model

References

[1] CHEN zhaonian, CHEN zichen:Machine tool thermal characteristic foundation study(China Machine Press, Beijing 1989)

[2] CHEN.J.S, HSU W Y.: Intemational Journal of Machine Tools and Manufacture Vol.43(2003) , pp.1345-1366

[3] Bernd.Bossmanns, Jay F. Tu:ASME Journal of Manufacturing Science and Engineering Vol.123(2001),pp.494-505

[4] WANG ke, ZHAGN yupu, SUN xingwei.: Mechanical Engineering & Automation Vol. 166(2011), pp.206-208
