Modeling Method of Interaction System for Intelligent GIS Based on IEC61850

Abstract:

GIS is now widely applied in power systems. It might lead to severe consequence when accidents take place, so online monitoring on GIS systems is necessary. Based on function analysis of the needs of GIS intelligent condition monitoring, a modeling method, a communication system and data exchanging interfaces, meeting IEC 61850 intrinsic ideas, are presented. Sharing and interacting strategies for intelligently-monitored GIS condition information are discussed. Focusing on MMS-based server/client communication mode, some information exchanging principles based on MMS messaging, logs and files are clarified. Server-client information exchanging communication programs are designed, and the flow charts of essential functions and client/server are also presented.

• Periodical: Advanced Materials Research (Volumes 718-720)
• Pages: 2163-2170
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.718-720.2163
• Online since: July 2013
• Authors: Pei Qing Miao, Xin Jian Tang, Feng Qing Du, Xing Lie Lei, Xiu Chen Jiang
• Keywords: GIS Condition Monitoring, IEC61850 Modeling, Information Interaction, Intelligent Power Equipment
