Solid Mass Flowrate Measurement System Using the Double-Elbow Method

Abstract:

The gas-solid flow is widely used in the enterprises. The real-time solid mass flowrate measurement is an important role to the enterprise production. Based on the gas flowrate measurement principle of the Elbow, the new Double-Elbow real-time solid mass flowrate measurement method in the gas-solid flow is brought out in this paper. The new method can finger out the mass flowrate directly and need not measure the mixture density in advance. The instrument on measuring the solid mass flowrate is developed based on the new method; the instrument is using the 8031 as the MCU; the measurement result can be displayed on the LED. The experiment on measuring the solid mass flowrate is carried out in the pneumatic conveying system. The experimental results prove that the instrument can be real-time on-line measuring the solid mass flowrate.

• Periodical: Advanced Materials Research (Volumes 718-720)
• Pages: 420-423
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.718-720.420
• Online since: July 2013
• Authors: Yan Jun Zhao, Fan Wei Meng, Bin Qu
• Keywords: Double-Elbow Method, Mass Flowrate, Measurement, Solid

References

[1] Li Haiqing, Huang Zhiyao, etc. Parameter measurement of two-phase flow and application. Zhejiang University Press, 1991.

[2] Klug F. and Mayinger F. Impedance based flow reconstruction-a novel flow composition measuring technique for multi-phase-flow, Nuclear Eng. Design, 2005, 146, pp.35-42

DOI: 10.1016/0029-5493(94)90318-2

[3] Li Zhi, Zhang Jin-feng, Zhou Zhenjiang, etc. research on the curved-pipe flowmeter. ACTA Metrologica Sinica, 2003, vol. 24 (3), pp.189-192

[4] Chen Xiuhua, Du Xianhua. Measuring massflow of pneumatic transport powdered coal by means of the momentum change. Journal of Southeast University, 1990, vol. 20 (2), pp.86-91

[5] Yuan Tao, Li Yuexiang, Yang Shenli. Principles and Application of Microcontroller Tsinghua University Press, 2012.3.
