The Optimization of the Pass Structure of Double Regenerative Burner with the Numerical Simulation of Thermal Stress Field

Abstract:

In order to solve the problem of cracks of the double regenerative burner, six kinds of low stress pass structures were newly developed and corresponding 3D CAE models were set up. With the FEM numerical simulations of thermal stress field of various combinations of different pass structures and the comparative study, the optimized pass structure that the thermal stress is relatively lower and thus can improve the service life of burner was determined.

• Periodical: Advanced Materials Research (Volume 721)
• Pages: 671-676
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.721.671
• Online since: July 2013
• Authors: Fan Zhi Jiang, Jian Yi Kong, De Gang Ouyang
• Keywords: Numerical Simulation, Regenerative Burner, Structure Optimization, Thermal Stress Field

References

[1] Huang Yongqiang, Fang Jinghua, The Application and Development of the Regenerative High Temperature Air Combustion in the Heating Furnace of Steel Rolling, J. Shanxi Energy and Conservation. 3(2002) 37-38.

[2] Cai Guowei, Cai Jiuju, Sun Wenqiang, Study on Some Problems in Regenerative Continuous Reheating Furnace Application, J. China Metallurgy.6(2008)36-39.

[3] Qi Jianjun, Bian Risheng, Xi Junliang, Application of Burner-Tip Heating Furnace With Two-Preheating And Two-Heat-Retaining, J. Hebei Metallurgy. 6(2001)53-55.

[4] Jiang Ciqiang, Zhang Yongqiang, Zhang Shuqiang, Application and Improvement of the Regenerative Burners on Heating Furnace J, Steel Rolling. 2(2010)71-72.

[5] Ding Cuijiao, Liu Zhaohui, Wang Lin, Numerical Simulation on Optimum Design of Regenerative Burner J. Industrial Furnace. 3(2010, 3)1-5.

[6] Kim JP, Schneliu, Scheffkneckt G, Comparison of Different Global Reaction Mechanisms for MILD Combustion of Natural Gas, J. Combust Sci&Tech. 4(2008)565-592.

[7] Sebastian M, Barbara P, Paul L, Simulation of Flameless Combustion of Natural Gas in A Laboratory Scale Furnace, J.Turkish J Eng Env Sei. 30(2006)135-143.

[8] Lv Yiqing, Sun Wei, Hou Weijun, Study and Design of Structure Optimization in Regenerative Burner of Reheating Furnace, J. Industrial Furnace. 4(2005)9-16.

[9] Du Jun, Rao Wentao, Simulation Research of Regenerative Cold-State Burner Structure Optimization, J. Bao Steel Technology. 2(2002)27-30.

[10] Zhu Jin-ming, Optimal Design of Heating Process for Heating Furnace of Regenerative Burners. J. Machine Building & Automation. 2(2011) 170-171.

[11] Li Caixia, Zhang Wei, Wang Cheng, Development and Application of Regenerative Box-Parts and Burner for Regenerative Reheating Furnace, J. Industrial Furnace. 5(2008) 47-50.

[12] Han Zhaolun, Fuel and combustion, second ed., Metallurgical Industry Press, Beijing, 1994.
