The Stress Calculation of Sidewall Rock in Hydraulic Fracturing Basing on Damage Theory

Abstract:

The sidewall rock area was divided into destruction zone, damage zone and elastic zone, considering that the fracturing fluid can cause sidewall rock damage and change the stress status of sidewall rock. The stress distribution calculation models for every zone were established basing on elasticity and damage mechanics. The relationship between radial stress, circumferential stress and destruction radius, damage zone was calculated. We can conclude from the calculation results that the radial stress and circumferential stress will increase with the distance away from the axis of wellbore increasing, and radial stress is greater than circumferential stress in destruction and damage zone. However, in elastic zone the radial stress and circumferential stress will decrease with the distance away from the axis of wellbore increasing. The radial stress approaches the maximum horizontal principle stress, and the circumferential stress approaches the minimum horizontal principle stress at last.

• Periodical: Advanced Materials Research (Volumes 734-737)
• Pages: 1493-1497
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.734-737.1493
• Online since: August 2013
• Authors: Chi Ai, Yu Liu, Yu Wei Li, Zhao Qi Wang
• Keywords: Damage Theory, Hydraulic Fracturing, Sidewall Rock Stress

References

[1] C.H. Yew, Y.Li. Fracturing of a Deviated Wells[J]. SPE16930.

[2] Xiongying Yu, Jiguo Xing, Xianying Wang. Research on Fracturing Pressure and Azimuth of a Deviated Well[J]. Journal Of Jianghan Petroleum Institute, 1994, 16(3): 57-60.

[3] Meng Wang, Guoshui Tang, Dong Wang. Physical Modeling Experiment of Rock Stress Distribution and Timbering Strength for Shaft[J]. Journal of Liaoning Technical University(Natural Science), 2009, 28(Supplement): 51-53.

[4] M.M. Hossain, M.K. Rahman. Hydraulic Fracture Initiation and Propagation: Roles of Wellbore trajectory, Perforation and Stress Regmes[J]. J.Pet. Sci&Eng, 2000, (27):129-149.

DOI: 10.1016/s0920-4105(00)00056-5

[5] M. M. Hossain, M. K. Rahman, S. S. Rahman. A Comprehensive Monograph for Hydraulic Fracture Initiation from Deviated Well bores under Arbitrary Stress Regimes[J]. SPE54360.

DOI: 10.2118/54360-ms

[6] Guangqing Zhang, Mian chen, Youquan Yin. Study on Influence of Perforation on Formation Fracturing Pressure[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22(1): 40-44.

[7] Dong Wang, Changwu Liu, Yuqiao Ding. Stability Analysis of Basalt Nude Inclined Shaft Surrounding Rock[J]. Metal Mine, 2010, (5): 148-151.

[8] Yunfang Zhai. Fluid Mechanics in Porous Medium[M]. Petroleum Industry Press, 2003, 9.
