Teager-Huang Transform Based Gear Crack Fault Detection and Diagnosis

Abstract:

The newly developed Teager-Huang transform (THT) enables one to look at the evolution in time of a signals frequency components. In this paper, a novel application of Teager-Huang transform method to fault diagnosis of gear crack is presented. The methodology developed in this paper decomposes the original times series data in intrinsic oscillation modes, using the empirical mode decomposition (EMD). Then the Teager Kaiser Energy Operator (TKEO) technique is applied to each intrinsic mode function (IMF). Therefore, the time-frequency distribution of the vibration is obtained. The basic method is introduced in detail. The Teager-Huang transform is applied in the research of the faults diagnosis of the gear crack. The experimental results show that Teager-Huang transform can effectively diagnosis the fault of the gear crack.

• Periodical: Advanced Materials Research (Volume 739)
• Pages: 418-422
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.739.418
• Online since: August 2013
• Authors: Ya Ning Wang
• Keywords: Empirical Mode Decomposition (EMD), Fault Detection, Gear, Signal Processing, Teager-Huang Transform, Time Frequency Analysis

References

[1] R. Rubini and U. Meneghetti: Application of the envelope and wavelet transform analyses for the diagnosis of incipient faults in ball bearings, Mechanical Systems and Signal Processing Vol. 15, No. 2, (2001), pp.287-302.

DOI: 10.1006/mssp.2000.1330

[2] J. Lin and L. Qu: Feature extraction based on Morlet wavelet and its application for mechanical fault diagnosis, Journal of Sound and Vibration, Vol. 234, No. 1, (2000), pp.135-148.

DOI: 10.1006/jsvi.2000.2864

[3] Hui Li, Yuping Zhang, Haiqi Zheng: Application of Hermitian wavelet to crack fault detection in gearbox. Mechanical Systems and Signal Processing, Vol. 25, No. 4, (2011), pp.1353-1363.

DOI: 10.1016/j.ymssp.2010.11.008

[4] Hui Li, Haiqi Zheng, Liwei Tang: Bearing Fault Diagnosis Based on Amplitude and Phase Map of Hermitian Wavelet Transform. Journal of Mechanical Science and Technology, Vol. 25, No. 11, (2011), pp.2731-2740.

DOI: 10.1007/s12206-011-0717-0

[5] N . E Huang, Z. Shen and S.R. Long et al: The empirical mode decomposition and the Hilbert spectrum for nonlinear and non-stationary time series analysis. Proceeding of Royal Society London, Series A Vol. 454, ( 1998), pp.903-995.

DOI: 10.1098/rspa.1998.0193

[6] P. Maragos, J.F. Kaiser, and T.F. Quatieri: On amplitude and frequency demodulation using energy operators. IEEE Transactions on Signal Processing, Vol. 41, No. 5, (1993), pp.1532-1550.

DOI: 10.1109/78.212729

[7] Hui Li, Haiqi Zheng, Liwei Tang: Bearing Fault Detection and Diagnosis Based on Teager-Huang Transform. International Journal of Wavelets, Multiresolution and Information Processing, Vol. 7, No. 5, (2009), pp.643-663.

DOI: 10.1142/s0219691309003173
