Nafion-Silane Modified Mordenite Composite Membrane Synthesis and Characterization for Direct Ethanol Fuel Cell

Abstract:

Composite membranes, consist of Nafion and surface-modified mordenite as inorganic filler functioned as ethanol barrier, were prepared and used for direct ethanol fuel cell (DEFC). mordenite was modified using gamma-glycidoxypropyltrimethoxysilane (GMPTS) which has the epoxide group and 3-mercaptopropyl-trimethoxysilane (MPTS) which has the mercapto group as coupling agents on mordenite. The composite membranes were fabricated by adding 5 %weight modified mordenite into Nafion by solution casting and hot pressing with catalyst to produce MEA and tested in DEFC single cell stack. XRD, FT-IR, Mastersizer and SEM were used to study the morphology, physical and chemical properties of the filler and the composite membrane. The characterizations also included ethanol permeability and proton conductivity by using the diffusion cell and AC impedance test, respectively. The performance of the cell was evaluated in the DEFC under cell temperature from 30 to 70 °C and ethanol concentration of 1 M to 4 M. It was then compared to the recasted Nafion membrane.

You might also be interested in these eBooks

Multi-Functional Materials and Structures IV

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 747)

Pages:

321-324

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.747.321

Citation:

Cite this paper

Online since:

August 2013

Authors:

Sawanya Kanjanapaisit, Chaiwat Prapainainar, Paweena Prapainainar

Keywords:

Composite Membrane, Direct Ethanol Fuel Cell (DEFC), Silane

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] V. A. Paganin, E. Sitta, T. Iwasita, and a. W. Vielstich, Methanol crossover effect on the cathode potential of a direct PEM fuel cell, Journal of Applied Electrochemistry, 35 (2005) 1239-1243.

DOI: 10.1007/s10800-005-9035-5

Google Scholar

[2] X. Li, E. P. L. Roberts, S. M. Holmes, and V. Zholobenko, Functionalized zeolite A–nafion composite membranes for direct methanol fuel cells, Solid State Ionics, 178 (2007) 1248-1255.

DOI: 10.1016/j.ssi.2007.06.012

Google Scholar

[3] K. Scott, W. M. Taama, and P. Argyropoulos, Performance of the direct methanol fuel cell with radiation-grafted polymer membranes, Journal of Membrane Science, 171 (2000) 119-130.

DOI: 10.1016/s0376-7388(99)00382-8

Google Scholar

[4] C. Yoonoo, C. P. Dawson, E. P. L. Roberts, and S. M. Holmes, Nafion®/mordenite composite membranes for improved direct methanol fuel cell performance, Journal of Membrane Science, 369 (2011) 367-374.

DOI: 10.1016/j.memsci.2010.12.030

Google Scholar

[5] H. Wu, B. Zheng, X. Zheng, J. Wang, W. Yuan, and Z. Jiang, Surface-modified Y zeolite-filled chitosan membrane for direct methanol fuel cell, Journal of Power Sources, 173 (2007) 842-852.

DOI: 10.1016/j.jpowsour.2007.08.020

Google Scholar

[6] H. Lin, C. Zhao, W. Ma, K. Shao, H. Li, Y. Zhang, and H. Na, Novel hybrid polymer electrolyte membranes prepared by a silane-cross-linking technique for direct methanol fuel cells, Journal of Power Sources, 195 (2010) 762-768.

DOI: 10.1016/j.jpowsour.2009.08.020

Google Scholar

[7] Y. Wang, D. Yang, X. Zheng, Z. Jiang, and J. Li, Zeolite beta-filled chitosan membrane with low methanol permeability for direct methanol fuel cell, Journal of Power Sources, 183 (2008) 454-463.

DOI: 10.1016/j.jpowsour.2008.06.003

Google Scholar

[8] Y. Wang, Z. Jiang, H. Li, and D. Yang, Chitosan membranes filled by GPTMS-modified zeolite beta particles with low methanol permeability for DMFC, Chemical Engineering and Processing: Process Intensification, 49 (2010) 278-285.

DOI: 10.1016/j.cep.2010.02.004

Google Scholar
