Estimation of Tensile Capacity of Single Anchors Including Edge Effect Using Neural Networks

Abstract:

The demand for more flexibility in the design and strengthening of concrete structures has resulted in an increased use of anchoring systems. Adhesive anchors are widely used in seismic strengthening applications to add new structural members or sections to existing concrete members. To safely design such anchors, it is very important to know their tensile capacity under axial tensile forces. This paper explores the pullout capacity of single adhesive anchors loaded in tension in un-cracked concrete. To this end 142 single anchor tests including edge effect (located near a concrete edge) were obtained from literature. The formulated three-layered artificial neural network method (ANN) was trained using 75% of the data set by using different learning algorithms. The methods were tested with the remaining 25% of the data set. The variables taken into account in this study are anchor diameter, embedment length, concrete body height and edge distance. It was determined that experimental data can be estimated to a notably close extent via the ANN model.

• Periodical: Advanced Materials Research (Volume 747)
• Pages: 424-428
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.747.424
• Online since: August 2013
• Authors: Murat Ozturk
• Keywords: Anchor, Neural Network Method, Tensile Capacity

References

[1] M. Ozturk, Prediction of Tensile Capacity of Adhesive Anchors Including Edge and Group Effects Using Neural Networks, Science and Engineering of Composite Materials, v. 20 (2013) 95–104.

DOI: 10.1515/secm-2012-0059

[2] Fuchs, W., Eligehausan, R., Breen, J.E., Concrete Capacity Design (CCD) Approach for Fastening to Concrete, ACI Structural Journal, v. 92 (1) (1995) 73-94.

DOI: 10.14359/1533

[3] Eligehausen, R., Appl, J. J., Lehr, B., Meszaros, J., and Fuchs, W., Tragverhalten und Bemessung von Befestigungen mit Verbunddübeln unter Zugbeanspruchung, Part 1: Einzeldübel mit großem Achs- und Randabstand (Load-bearing Behavior and Design of Fastenings with Adhesive Anchors under Tension Loading – Part 1: Single Anchors with Large Axial and Edge Spacing), Beton und Stahlbetonbau 99 (2004).

DOI: 10.1002/best.200490142

[4] Cook, R.A., Kunz, J., Fuchs, W., Konz, R.C., Behavior and Design of Single Adhesive Anchors Under Tensile Load in Uncracked Concrete, ACI Structural Journal, vol. 95 (1) (1995) 9-26.

DOI: 10.14359/522

[5] Cook, R. A., Eligehausen R., Appl. J., Overview: Behavior of Adhesive Bonded Anchors, Beton und Stahlbetonbau, 102 (2007) special edition 16-21.

DOI: 10.1002/best.200710107

[6] Lehr, B., Tragverhalten von Verbunddübeln unter zentrischer Belastung im ungerissenen Beton – Gruppenbefestigungen und Befestigungen am Bauteilrand, (Load-Bearing Behavior of Adhesive Anchors under Axial Tension in uncracked concrete – Anchor Groups and Anchors close to an edge), Doctoral thesis, University of Stuttgart, Germany (in German) (2003).

DOI: 10.1002/best.200590230
