Space-Charge-Limited Bipolar Currents at High Fields in Polymer/C₆₀ Diodes: A Simple Model Description

Abstract:

We investigate the dark transport properties of organic photovoltaic devices formed by a heterojunction of a semiconducting co-polymer and the fullerene (C₆₀) [. The copolymers are composed of thiophene, phenylene and fluorene units, where the thiophene content was kept constant while the fluorene/phenylene ratio was varied. Measurements show that for low voltage, the current versus voltage (j x V) characteristics presents an exponential increasing, typical of a diode behavior. On the other hand, the j x V curves are space-charge limited at high voltages. This latter response follows the theoretical predictions proposed by Koehler et al in Ref. [ (see also [), which explains the dark current in polymer/fullerene photodiodes at high V's. To describe the full j x V characteristics, we have extended the analysis in Ref. [ assuming a space-charge dependent inner series resistance. From such model we are able to nicely fit the experimental curves, to estimate the effective mobility in the whole device and to obtain the diode reverse saturation current j₀. Finally, the results indicate that the copolymer with the highest effective total mobility is the PFT [(9,9dihexyl-9H-fluorene-2,7-diyl)-1,2-ethenediyl-2,5-thiophene-1,2ethenediy.

• Periodical: Advanced Materials Research (Volume 747)
• Pages: 591-594
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.747.591
• Online since: August 2013
• Authors: Natasha A.D. Yamamoto, Deize C. Grodniski, Lucimara S. Roman, Marlus Koehler, Marcos G.E. da Luz
• Keywords: Diode, Fullerene, High Applied Fields, Organic Photovoltaic Devices, Semiconducting Co-Polymers, Transport Properties

References

[1] N. A. D. Yamamoto et al, Synthesis and Solar Cell Application of New Alternating Donor Acceptor Copolymers Based on Variable Units of Fluorene, Thiophene, and Phenylene, J. Phys. Chem. C 116 (2012) 18641-18648.

DOI: 10.1021/jp305427g

[2] M. Koelher, L. S. Roman, O. Inganas, M. G. E. da Luz, Space-charge limited bipolar currents in polymer/C60 diodes, J. Appl. Phys. 92 (2002) 5575-5577.

DOI: 10.1063/1.1509839

[3] M. Koelher, L. S. Roman, O. Inganas, M. G. E. da Luz, Modeling bilayer polymer/fullerene photovoltaic devices, J. Appl. Phys. 96 (2004) 40-43.

[4] T. Ahn, S. Y. Song, H. K. Shim, Highly photoluminescent and blue-green electroluminescent polymers: New silyl- and alkoxy-substituted poly(p-phenylenevinylene) related copolymers containing carbazole or fluorene groups, Macromolecules 33 (2000).

DOI: 10.1021/ma000449c

[5] N. A. D. Yamamoto et al, Effect of the Temperature of Annealing on the Performance of Fluorene and Bithiophene Copolymer in Bilayer Solar Cells. Materials Research Society Symposia Proceedings 1390 (2012) h13-65.

[6] C. F. N. Marchiori et al, Performance of fluorene and terthiophene copolymer in bilayer photovoltaic devices: The role of the polymer conformations, Organic Electronics 13 (2012) 2716-2726.

DOI: 10.1016/j.orgel.2012.08.002
