Analysis of Vibration Characteristics Basing on a Multi-Rigid Suspension Model and a Multi-Flexible Suspension Model

Abstract:

The torque vibration derived from in-wheel-motor transmitted to body frame through suspension system without the absorption of mechanical transmission parts, then excited every body panel to shape the vehicle interior noise, which influenced the quality of the vehicle NVH. This paper aims to build an accurate suspension system simulation model to analyze the influence of suspension parts parameters to system vibration transmission property. Basis on a novel empirical model of rubber bushing, a multi-rigid suspension model and a multi-flexible suspension model had been established respectively. The vibration characteristics of two models were simulated, furthermore the swept-sine exciting vertical force signal on wheel contact point were input on the simulation models to find the difference between rigid and flexible model. The simulation results show that: the multi-flexible model can reflect the vibration characteristics of the suspension system more accurately in the high frequency range and so is it more applicable to the simulation analysis of vibration characteristics of in-wheel-motor electric vehicle suspension system.

• Periodical: Advanced Materials Research (Volume 748)
• Pages: 427-431
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.748.427
• Online since: August 2013
• Authors: Xue Ying Li, Zhuo Ping Yu, Zeng Liang Yu, Lu Xiong
• Keywords: Multi-Flexible Suspension Model, Multi-Rigid Suspension Model, Novel Empirical Model of Rubber Bushing, Vibration Characteristics

References

[1] YU Zeng-liang; ZHANG Li-jun; YU Zhuo-ping. Semi-Empirical Parameterized Dynamic Model of Rubber Bushing Mechanical Properties[J]. Journal of Mechanical Engineering, 2010, 46(14) PP: 115-123.

DOI: 10.3901/jme.2010.14.115

[2] YU Zeng-liang; ZHANG Li-jun; LUO Ying. A Novel Semi-Empirical Dynamic Model of Rubber Bushing[J], Automobile Technology, 2010(8), PP: 6-11.

[3] Ichiro Kido, Akeru Nakamura et al. Suspension Vibration Analysis for Road Noise Using Finite Element Model [J]. SAE1999-01-1788.

[4] HU Hong-xing. Experimental Validation of a Half-Vehicle Suspension Model [J]. SAE931966.

[5] H. Douville, P. Masson et al. On-resonance transmissibility methodology for quantifying the structure-borne road noise of an automotive suspension assembly [J]. Applied Acoustics, 2006(67): 358-382.

DOI: 10.1016/j.apacoust.2005.07.002

[6] Hisanori Tachibana, Kazuhiko Gotoh, Hitomi Sakab. Vibration Analysis of Driveline and Suspension Using Finite Element Models [J]. SAE931306.
