Switch Technology in Intelligent Substation

Abstract:

As the technology of intelligent substation is developed gradually, the significance of he Ethernet switch in the substation is obvious increasingly.Firstly, the learning and transmitting principle of Ethernet frame are introduced, then the network program of secondary system using the switch in the hierarchial structure is described. And then a detailed analysis of the VLAN, QoS, mirror and ring network is given, also the various technical application scheme are provided according to a variety of IED features and data flow characteristics. On the basis of the different business needs and different message types, the reasonable design of network topology and the flexible use of these switching technology , can support security, stability, reliable transmission of communication message in intelligent substation , therefore the whole substation becomes more strong.

• Periodical: Advanced Materials Research (Volume 748)
• Pages: 468-472
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.748.468
• Online since: August 2013
• Authors: Xiang Qun Wang, Zeng Hua Zhang, He Wang, Chun Long Li, Xiao Yan Sun, Wei Wang
• Keywords: Intelligent Sub-Station, Mirror, Multicast, QoS, Switch, VLAN

References

[1] IEC61850, Communication networks and systems in substations[S]. (2003).

[2] XU Cheng-bin, SUN Yi. min. A communication solution of process layer GOOSE in digitized substation[J]. Automation of Electric Power Systems, 2007, 3 1(1 9): 91-94.

[3] CAO Jinping, LI Wei, QIN Yingli, HUANG Xin. Research on digital substation proless level communication technology[J]. Power System Protection and Control, 2008, 36(12): 60-63.

[4] CAO Jinming, FANG Xinyan, WU Rong. Reliable substation communication based on IEC61850[J]. Electric Power Automation Equipment, 2008, 28(9): 89-93.

[5] TONG Xiaoyang, L I Yingchuan, CHEN Deming, ZHA NG Li, XU Kelai. Refined Management Study of the Digital Substation Secondary System Based on IEC61850[J]. Automation of Electric Power Systems, 2009, 33(22): 44-48.

[6] NIU Zhan-ping. Application of VLAN technology in the intelligent substation network[J]. Power System Protection and Control, 2009, 37(23): 75-78.

[7] CAO Haiou, YAN Guoping, XU Ning, LI Cheng. GOOSE networking scheme for mgital substation[J]. Electric Power Automation Equipment, 2011, 31(4): 143-146.

[8] DING Daiyong, WANG Liping, WANG Xiaoru. Research on Application of Multicast in Low Voltage Substation Communication[J]. Power System Technology, 2011, 31(4): 143-146.

[9] YIN Haichun. Implementation of IGMP snooping protocol on the switch layer[D]. Chengdu: Chim University of ElectronicScience and Technology, (2004).

[10] ZHU Laiqiang, CHEN Xinzhi, GAO Zhiyong. Prevention of digital substation broadcast storm[J]. 2010, 30(11): 98-100.
