Static Deformation of Precision Machine Tools for Large Scale Aspheric Components Manufacure

Abstract:

Large scale aspherical optical component plays an important role in National defense industry. It is based on the large size aspherical machine tools, so the stiffness and accuracy of the machine tools lead to the accuracy of the mirror directly. The tools consist of a turntable shaft and three linear axes including X/Y/Z axises. This paper analyzes a desirable arrangement of Y-axis linear motors so that the error of Y-axis produced indirectly can be minimized.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 1069-1073
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.1069
• Online since: August 2013
• Authors: Shi Long Liu, Shuming Yang, Zhuang De Jiang, Yu Kun Xu, Jin Long Wang, Guang Tao Yuan
• Keywords: Accuracy, Hydrostatic Guideway, Linear Motor, Precision Machine Tools

References

[1] ZHANG Lei，HUANG Zhi-dong，ZHAO Ji，Motion generation for machining axisymmetric aspheric surface based on analysis method. Journal of Jilin University, 2013, 43(01): 28-33.

[2] ZHOU Xusheng, DAI Yifan, LI Shengyi, ZHENG Ziwen, WANG Guilin, Design of An Aspheric Surface Machine Tool. Manufacturing Technology & Machine Tool, 2004(05): 55-57.

[3] ZHANG Jianming, Research and development of modern ultra-precision processing technology and equipment. Aviation Precision Manufacturing Technology, 2008(01): 1-7.

[4] YANG Qing-quan, GUO Yin-biao, LIU Wei-hua, XIE Shu-tong, Design and Implementation on the High Speed Turning System of Aspherics. Journal of Xiamen University, 2009, 48(05): 691-694.

[5] LI Yong, ZHANG Xiang-yang, XIE Xiao-dan, Development of Ultra-Precision Machine for Large-Sized Mirror Surface. Nanotechnology and Precision Engineering, 2012(05): 428-432.

[6] LI Guo, DONG Shen, ZHANG Jing-he, WANG Hai-feng, ZHANG Shun-guo, A Large-Scale Aspheric Surface Ultra-Precision Hybrid Machine Tool, Nanotechnology and Precision Engineering, 2006(01): 75-78.

[7] WANG Hongxiang, SONG Xingyong, ZHANG Longjiang, Development of aspherical ultra- precision machine tools. Mechanical Engineer. 2005(05): 14-15.

[8] ZHANG Shu, WEI Hanhua, TAN Huimin, HUANG Zhongming, High Precision and Ultra Precision Machine Tool. Aeronautical Manufacturing Technology. 2012(09): 40-44.

[9] WANG Wenyan, Some Measures on Improving Precision of Slideway in Precise Machine Tools. Tianjin Metallurgy. 2000(04): 43-45.

[10] WANG Yanhui, WU Jianguo, LIAO Jiancheng, Optimization Design for the Structure Variables of Precision Machine Tool Bed. Machine Design and Research. 2003(06): 53-54+38-8.

[11] NI Zhenhua, Vibration Mechanics. Xi'an Jiaotong University Press. (1990).
