Effect of the Fiber Length of Optoelectronic Oscillator on Sensitivity of Distance Measurement

Abstract:

The ultra-long optical fiber of optoelectronic oscillator (OEO) and the high spectral purity of the high frequency microwave signal open the possibility of high-accuracy distance measurement at long range. Sensitivity of distance measurement is highly depending on the length of the cavity. Base on the theory of optoelectronic oscillator and the distance measurement method, the sensitivity is calculated and the demand for spectral-purity of microwave signal are proposed and verified by experiments. Consider the demands of the measurement sensitivity, the spectral purity and the measurement range, as well as the error introduced by environment, the fiber length of OEO would be about 1km when the resolution of frequency measurement is 1Hz.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 2099-2102
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.2099
• Online since: August 2013
• Authors: Tao Zhang, Ji Gui Zhu, Sheng Hua Ye
• Keywords: Fiber Length, Measurement, Measurement Sensitivity, Optoelectronic Oscillator

References

[1] I. Fujima, S. Iwasaki, and K. Seta, High-resolution distance meter using optical intensity modulation at 28 GHz, Measurement Science and Technology 9, 1049 (1999).

DOI: 10.1088/0957-0233/9/7/007

[2] K. Meiners-Hagen, R. Schödel, F. Pollinger, and A. Abou-Zeid, Multi-Wavelength Interferometry for Length Measurements Using Diode Lasers, Measurement Science Review 9, 16-26 (2009).

DOI: 10.2478/v10048-009-0001-y

[3] K. Minoshima and H. Matsumoto, High-Accuracy Measurement of 240-m Distance in an Optical Tunnel by use of a Compact Femtosecond Laser, Appl. Opt. 39, 5512-5517 (2000).

DOI: 10.1364/ao.39.005512

[4] R. D. Nicolae, M. -H. Karl, W. Martin, P. Florian, and A. -Z. Ahmed, Absolute distance measurement system using a femtosecond laser as a modulator, Measurement Science and Technology 21, 115302 (2010).

DOI: 10.1088/0957-0233/21/11/115302

[5] J. Lee, Y. -J. Kim, K. Lee, S. Lee, and S. -W. Kim, Time-of-flight measurement with femtosecond light pulses, Nat Photon 4, 716-720 (2010).

DOI: 10.1038/nphoton.2010.175

[6] D. Nguyen Lam, B. Journet, I. Ledoux-Rak, J. Zyss, N. Luong Vu Hai, and L. Vu Van, Opto-electronic oscillator: Applications to sensors, in Microwave photonics, 2008. jointly held with the 2008 asia-pacific microwave photonics conference. mwp/apmp 2008. international topical meeting on, 2008), 131-134.

DOI: 10.1109/mwp.2008.4666653

[7] X. S. Yao and L. Maleki, Optoelectronic microwave oscillator, J. Opt. Soc. Am. B 13, 1725-1735 (1996).

[8] D. A. Howe and A. Hati, Low-noise x-band oscillator and amplifier technologies: comparison and status, in Frequency Control Symposium and Exposition, 2005. Proceedings of the 2005 IEEE International, 2005), 481-487.

DOI: 10.1109/freq.2005.1573978

[9] X. S. Yao and L. Maleki, Converting light into spectrally pure microwave oscillation, Opt. Lett. 21, 483-485 (1996).

DOI: 10.1364/ol.21.000483

[10] D. Eliyahu, K. Sariri, J. Taylor, and L. Maleki, Optoelectronic oscillator with improved phase noise and frequency stability, in (SPIE, 2003), 139-147.

DOI: 10.1117/12.475834
