Modeling and Analysis of Planar Multibody System Containing Deep Groove Ball Bearing with Slider-Crank Mechanism

Abstract:

With the rotating machinery system developing toward high speed, high precision, and high reliability direction, ball bearing dynamic performance have a critical impact to dynamics characteristics of support system. Based on multibody dynamics theory and contact dynamics method,and considering the ball and ring raceway 3 d dynamic contact relationship, using ADAMS dynamics analysis software to establish the multibody dynamics model of crank slider mechanism containing ball bearing dynamic contact relationship.The simulation analysis of the dynamic performance of the ball bearing and the crank slider mechanism dynamics response, and the influence of dynamic performance for considering ball bearing rotating mechanical system dynamics analysis provides a reference method.The simulation analysts the influence of dynamic performance of the ball bearing to the crank slider mechanism dynamics response. It provides a reference method for rotating mechanical system dynamics analysis considering the dynamic performance of the ball bearing.

• Periodical: Advanced Materials Research (Volumes 753-755)
• Pages: 918-923
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.753-755.918
• Online since: August 2013
• Authors: Ao Sun, Ting Qiang Yao*
• Keywords: Ball Bearing, Clearance, Contact Analysis, Dynamic, Simulation Analysis, Slider-Crank Mechanism

References

[1] Xu Li-xin, Yang Yu-hu, Li Yong-gang, Li Chong-ning, Wang Shi-yu. Modeling and analysis of planar multibody systems containing deep groove ball bearing with clearance. Mechanism and Machine Theory 56 (2012) 69–88.

DOI: 10.1016/j.mechmachtheory.2012.05.009

[2] Yao Ting-qiang, Chi Yi-lin, Huang Ya-yu, Tan yang. Rigid and Flexible Contact Dynamics Analysis on Rolling Bearing. China Mechanical Engineering(2008) Vol. 9 , 16: 1924-(1928).

[3] Yao Ting-qiang, Chi Yi-lin, Huang Ya-yu. Contact Dynamic Analysis of Angular Ball Bearing Considering Influence of Force. Bearing 2007, No. 4: 23-26.

[4] Zhu Li-jun, Tan jing, Huang Di-shan, Xu Yang, Fu Hui-yan. Simulation Analysis of Deep Ball Bearings Based on ADAMS. Bearing 2011, No. 2: 3-6.

[5] Lankarani H M, Nikravesh P E. Continuous Contact Force Models for Impact Analysis in Multibody Systems. Nonlinear Dynamics, 1994(5): 193-207.

DOI: 10.1007/bf00045676

[6] Dietl P. Damping and Stiffness Characteristics of Rolling Element Bearings Theory and Experiment. PHD Thesis Technical University of Vienna , Austria, (1997).
