Research on Dynamic Characteristics of Large Span Transmission Tower in Icing Environment

Abstract:

The transmission tower with a big span in the freezing area is very sensitive to climate. When extreme weather approaches, the tower may collapse easily. The dynamic characteristics of transmission tower structure vary under different weather conditions. This paper, taking a 500kV long span tangent tower as the research subject, will demonstrate the dynamic characteristics of such structures when the weight of wires, the icing stiffness of tower structure and the thickness of ice are considered. The results show that icing has a great impact on the dynamic characteristics of the tower structure and it can not be neglected. When the ice is thick, the contribution of icing to the stiffness of the structure should be considered. This conclusion can provide a reference for the analysis and design of similar towers in high altitude area.

• Periodical: Advanced Materials Research (Volumes 756-759)
• Pages: 4262-4266
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.756-759.4262
• Online since: September 2013
• Authors: Yue Du, Lan Jiang, Yu Xin Zhou, Qiao Rong Li, Tai Ran Wan, Zi Jun Pan
• Keywords: Dynamic Characteristic, High Voltage Transmission, Icing, Transmission Tower Line System

References

[1] Li H N, Bai H F. State-of-the-art review on studies of disaster resistance of high-voltage transmission tower line systems [J]. China Civil Engineering Journal. 2007, 40(2): 39-46.

[2] Ruan Lingli, Du Zhengjing, Su Huaying, ELECTRICAL EQUIPMENT . 2008 and ice storms in early the Guizhou power industry disaster impact assessment [J]. The Guizhou Meteorological, 2009 Supp 33: 89-91.

[3] Chengqi Li , Zhang sang high altitude , multi- Freezing regional solutions to solve the problem of the Transmission Line Research and Application of 2008 anti -ice protection electrical outstanding Proceedings . 192-197.

[4] Yuan J H, Jiang X L, Yi H, The present study on conductor icing of transmission lines [J]. High Voltage Engineering, 2004, 30(1): 6-9.

[5] ZHOU Honggang, HAN Xiaolin, FEI Qing guo, Dynamic Property Analysis of Iced Long-span Transmission Tower-line System [J]. Journal of Disaster Prevention and Mitigation Engineering. 2010, 30(2): 185-189.

[6] DAI Hongzhe, Wang Wei, YUAN Ping, ZHENG Tianxin . Dynamic behavior analysis of transmission line system [J]. JOURNAL OF HARBN NSTITU OF TECHNOLOGY. 2008, 40(2): 1906-(1999).

[7] National standards of P.R.C. Code for design of steel structures[S]. China plans to press. beijing: (2003).

[8] Chen Kequan , Yan Bo, Zhang Hongyan, Zhou Song. Numerical simulation of de-icing on transmission lines under shock load [J], CHINESE JOURNAL OF APPLIED MECHANICS. 2010, 27(4): 761-766.

[9] MENG Suimin, KONG Wei, Overhead transmission line design[M]. China electric power press. BeiJing: 2007. 8.

[10] JIANG Lan, ZHANG Huagang, YUAN Bo, HUO Wenxing. Research on vibration response of long-span reinforced concrete open-web sandwich plate structures under walking excitation[J]. Sichuan Building Science. 2012, 38(1): 9-13.
