Development of Diagnostic Equipment for ECU Parts Used in Electric Vehicles

Abstract:

Electric vehicles use lots of ECU controllers in the CAN network, the quality of ECU parts used in vehicles is closely related to safe driving. This paper develops a kind of fault diagnostic equipment for electric vehicles ECU controllers. This device has designed digital input signal acquisition module, the output switch signal module, power supply module and fault simulation module based on CAN bus communication principle. Then we use LabVIEW developing computer program in order to monitor and control the whole system.

• Periodical: Advanced Materials Research (Volumes 756-759)
• Pages: 4454-4459
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.756-759.4454
• Online since: September 2013
• Authors: Jin Rui Nan, Jun Kui Huang, Zhi Chai
• Keywords: CAN Bus, ECU, Electric Vehicle (EV), Fault Diagnosis, LabVIEW

References

[1] Chunming Zhao, Xutong Qiao, and Ning Ma, The study on distributed control diagnostic system on electric vehicles based on CAN Bus, Vehicle&Power Technology, Phase II of the (2005).

[2] Robert Ball, Diagnostic Strategy for Hybrid-Electric and Electric Commercial Vehicles, Azure Dynamics Ltd Topic 5: Vehicle Architectures and Ancillaries, Robert Ball, Azure Dynamics Ltd, Units I&J, Princes Drive Industrial Estate, Kenilworth, CV8 2FD.

DOI: 10.1049/cp:20060603

[3] Yingji Liu, Tianxia Zhang, and Wanke Cao, Research of fault diagnosis of electric appliance for vehicle based on CAN Bus, International Technology and Innovation Conference (2006).

DOI: 10.1049/cp:20061163

[4] Haijing Gong, Houjun Tang, and Jun Kong, The Research of CAN Bus in electric cars, process control computer, seventeenth volume third issue, (2004).

[5] LabVIEW Function and VI Reference Manual [M], National Instruments Corporation, (1998).

[6] Maki. Y and Loparo.K. A(1997), A Neural network approach to fault detection and diagnosis in Industrial processes, IEEE Transactions on control systems technology, V01．5，No. 6 , 520-540.

DOI: 10.1109/87.641399

[7] ISO 11898 Vehicle[Z]–Digital Information Interchange–High Speed Communication Controller Area Network．(Version 1), 1993, (11): 5-120. M. Young, The Technical Writer's Handbook. Mill Valley, CA: University Science, (1989).
