Influence of Calcined Temperature on the Piezoelectric Properties of (Na_0.48K_0.47Li_0.05)NbO₃ Lead-Free Piezoelectric Ceramics Doped with CuO

Abstract:

Na_0.48K_0.47Li_0.05)NbO₃(NKLN)Lead-free piezoelectric ceramics doped with CuO were prepared by traditional solid-state reaction method. Influence of calcined temperature on the material phase of NKLN lead-free piezoelectric ceramics doped with CuO by X-ray diffraction (XRD) and the influence of calcined temperature and sintered temperature on the properties of NKLN lead-free piezoelectric ceramics doped with CuO by others analysis method. The results show that the best calcined temperature is got, when calcined temperature is up to 850 °C, the mixed phase disappeares, a single phase perovskites structure is formed. With the increase of calcined temperature, piezoelectric strain constant (d₃₃) planar electromechanical coupling factor (K_p) of NKLN lead-free piezoelectric ceramics increase first and then decrease, while only dielectric loss (tanδ) decreases first and then increases.The best calcined temperature is 850 °C, the best sintered temperature is 1080 °C, the NKLN lead-free piezoelectric ceramics doped with CuO with good comprehensive properties are obtained, whose d₃₃ , K_p , tanδ are 85 pC/N, 0.3, 0.038, respectively.

• Periodical: Advanced Materials Research (Volumes 760-762)
• Pages: 763-766
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.760-762.763
• Online since: September 2013
• Authors: Xin You Huang, Mu Sheng Huang, Chun Hua Gao
• Keywords: Calcined Temperature, CuO Doped, Lead-Free Piezoelectric Ceramics, Lithium Sodium Potassium Niobate

References

[1] B. Jaffe, W.R. Cook and H. Jaffe: Piezoelectric Ceramics (Academic Press, New York 1971).

[2] D.Q. Xiao: Electronic Components Materials Vol. 23 (2004), p.62.

[3] D.J. Gao, K. W. Kwok, D.M. Lin, H. L. W. Chan: J. Phys. D: Appl. Phys. Vol. 42 (2009), p.035411.

[4] D.M. Lin, K.W. Kwok, H.L.W. Chan: Applied Physics A: Materials Science and Processing Vol. 91(2008), p.167.

[5] D.J. Gao, K.W. Kwok, D.M. Lin, H.L.W. Chan: Mater. Science Vol. 44 (2009), p.2466.

[6] Y. Sun, D.Q. Xiao, L. Wu, M. Chen, D.M. Lin, J.G. Zhu: Journal of Functional Materials Vol. 38 (2007), p.1225.

[7] T. Tani: J. Ceram. Soc. Jpn. Vol. 114 (2006), p.363.

[8] Y. Saito, T. Hisaaki, T. Tani : Nature Vol. 432 (2004), p.84.

[9] X.K. Niu, J. L. Zhang: Solid State Commun Vol. 146 (2008), p.395.

[10] G. Z. Zang, J. F. Wang, H. C. Chen: Appl. Phys. Lett. Vol. 88 (2006), p.212908.

[11] H. Takao, Y. Saito : J. Am. Ceram. Soc. Vol. 89 (2006), p. (1951).

[12] S.H. Park, C.W. Ahn, S. Nahm, J.S. Song: Japanese Journal of Applied Physics Vol. 43 (2004), p.1072.
