Research on Fuel Cell Power Generation System Model with Grid

Abstract:

The paper take the solid oxide fuel cell (Solid Oxide Fuel Cell, SOFC) as the object, studies the influence of the fuel cell on load characteristics of the distribution network. Structures based on Matlab simulation platform contains the SOFC typical distribution network, and a series of transient simulation was conducted, results indicate that the SOFC power generation system can be describe in its equivalent model based on the URL equivalent circuit-order differential equation of state. On this basis, the access to the distribution network SOFC power generation system regarded as power consumption of the negative dynamic load, proposed containing the SOFC can be to the equivalent the GSLM model containing the SOFC described distribution grid load characteristics.

• Periodical: Advanced Materials Research (Volumes 765-767)
• Pages: 2417-2420
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.765-767.2417
• Online since: September 2013
• Authors: Ming Hua Zhou, Qun Su
• Keywords: Distributed Power, Fuel Cell (FC), Mathematical Models

References

[1] Padulles J, Ault G W, McDonald J R. An integrated SOFC plant dynamic model for power systems simulation. Journal of Power Source, 2000, 86(1): 495-500.

DOI: 10.1016/s0378-7753(99)00430-9

[2] Chiara Boccaletti, Gianluca Fabbri, Ezio Santini. A Reformer Model for Fuel Cell Power Systems. In: Proc of Int Conf on Power Engineering-Energy and Electrical Drives. Setubal, 2007: 347-352.

DOI: 10.1109/powereng.2007.4380209

[3] QIAN Jun, LI Xinran, WANG Ling, MA Yahui. Load Modeling Oriented Modeling of Photovoltaic Cell and Fuel Cell and Its Equivalent Description. Power System Technology, 2011, 35(4): 135-142.

[4] WANG Ling, LI Xinran, MA Yahui, etc. Dynamic Model of Fuel Cell Power Generating System. Proceedings of the CSEE, 2011, 31(22): 40-47.

[5] ZHANG Jian, SUN Yuanzhang, PENG Xiaotao, etc. Generalized Load Modeling With Solid Oxide Fuel Cell Considered. Proceedings of the CSEE, 2011, 31(4): 78-84.

[6] Y H Li, S S Choi, Rajakaruna S. An Analysis of the control and operation of a solid oxide fuel-cell power plant in an isolated system. IEEE Transactions. on Energy Conversion, 2005, 20(2): 381-387.

DOI: 10.1109/tec.2005.847998

[7] DING Ming, YAN Liu-jin, MAO Mei-qin, etc. Modeling and Control of Fuel Cells in Distributed Generation System. Power System Technology, 2009, 33(9): 8-13.

[8] GU He-rong, YANG Zi-long, WU Wei-yang. Research on Hysteresis-band Current Tracking Control of Grid-connected Inverter. Proceedings of the CSEE, 2006, 26(9): 108-112.
