Simulation about Multi-Frequency Modulator of Light Impulse Used in LAPS Array

Abstract:

Two kind of frequency modulator to produce multi-frequency light impulse array and a kind of measurement system for light addressable potentiometric sensor (LAPS) array are introduced based on micro-lens and frequency modulator disk. Simulation of FFT is used to analyze the available photocurrent signals of LAPS array with MATLAB. According the simulation spectrum, the corresponding photocurrent signals of light impulse with different frequencies are able to resolve. When the duty ratio is larger than or equal to 30%,the construction of the frequency modulator can be simplified, which further prove that LAPS array with multi-frequency light impulses is provided with reliable resolution .All of above provides enough theoretical foundation for preparation and signal processing of LAPS array device .

• Periodical: Advanced Materials Research (Volumes 765-767)
• Pages: 2563-2566
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.765-767.2563
• Online since: September 2013
• Authors: Wei Jun Hu
• Keywords: Duty Ratio, Light Impulse, Multi-Frequency Modulator, Simulation

References

[1] D.G. Hafeman, et al., Light-addressable potentiometric sensor for biochemical systems, Science 240 (1988) 1182–1185.

DOI: 10.1126/science.3375810

[2] Y. Mourzina, M.J. Schoning, J. Schubert, et al., A new thin-film Pb microsensor based on chalcogenide glass, Sensors and Actuators B 71 (2000) 13–18.

DOI: 10.1016/s0925-4005(00)00557-8

[3] J. Schubert M.J. Schoning Y.G. Mourzina, et al., Multicomponent thin film for electrochemical sensor applications prepared by pulsed laser deposition, Sensors and Actuators B 76 (2001) 327–330.

DOI: 10.1016/s0925-4005(01)00616-5

[4] Z. Qintao, W. Ping, W.J. Parak, et al., A novel design of multi-light LAPS based on digital compensation of frequency domain, Sens. Actuators B 73 (2001) 52–156.

DOI: 10.1016/s0925-4005(00)00696-1

[5] H. Jinghong, L. Weiguo, Z. Hong, C. Deyong, X. Lei, Research of properties on the bio-chemical mocro-array light addressable potentiometric sensor system, J. Electron. Inform. Technol. (Chinese) 25 (6) (2003) 831–837.

[6] Weijun Hu , Hua Cai, Jing Fu, Ping Wang, Guoguang Yang, Line-scanning LAPS array for measurement of heavy metal ions with micro-lens array based on MEMS Sensors and Actuators B 129 (2008) 397–403.

DOI: 10.1016/j.snb.2007.08.042
