Effect of Orientation of Reinforcements on the Quality of the Machined Surface in Machining Aluminium Composites

Abstract:

The precision turning experiments of aluminium composites reinforced with SiC whisker reinforcements were done by polycrystalloid diamond (PCD) tools. The measure analysis of the machined surface was carried out with Atom Force Microscope (AFM) and Scan Electronic Microscope (SEM). The roughness values of the machined surface were measured by Talysurf-6. The results show that the orientation of reinforcements in the machined surface will directly affect the deformation mechanism of SiC whiskers, microstructures of the machined surface, and to determine the quality of the machined surface. In the five types from A to E of SiC whisker orientation, the orientation of case A easily makes to produce SiC whisker deformation by cutting off directly, and to result in the best machined surface. However, for the orientation of case E, it easily makes to induce SiC whisker deformation by pulling out or pressing into aluminium matrix, and to produce the worst machined surface.

You might also be interested in these eBooks

Advanced Technologies in Manufacturing, Engineering and Materials

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 774-776)

Pages:

1032-1037

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.774-776.1032

Citation:

Cite this paper

Online since:

September 2013

Authors:

Da Zhen Wang, Pei Feng Feng

Keywords:

Aluminum Composite, Deformation Mechanism, Orientation, Precision Machining, SiC Whisker

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] D Z Wang, H M Liu, R D Han. Tribology, Vol. 120(2), pp.85-89(in Chinese).

Google Scholar

[2] D Z Wang, P F Feng, Q L Zhao. Journal of Astronautics, Vol. 27(6), pp.1341-1346(in Chinese).

Google Scholar

[3] Y M Qual, B Y Ye. Journal of materials processing technology, Vol. 138, pp.464-467.

Google Scholar

[4] Z J Yuan, L Geng. Annals of the CIRP, Vol. 42(1), pp.107-109.

Google Scholar

[5] D Z Wang, R D Han, H M Liu. tribology, Vol. 25(6), pp.569-573(in Chinese).

Google Scholar

[6] Kilichap E, Cakir O, Aksoy M. Journal of material processing technology, Vol. (164-165), pp.862-867.

Google Scholar

[7] Cheung C F, Chan K C, Lee W B. Journal of materials processing technology, Vol. 140, pp.141-146.

Google Scholar

[8] Mohan B, Rajadurai A, Satyanarayana G. Journal of materials processing technology, Vol. (153-154), pp.978-985.

Google Scholar

[9] Gallae M E, Sklad M P. Journal of materials processing technology, Vol. (152), pp.23-34.

Google Scholar

[10] Mohan B, Rajadurai A, Satyanarayana G. Journal of materials processing technology, Vol. (124), pp.297-304.

Google Scholar

[11] G Q Liang, J F Zhang. Applied Mechanics and Materials, Vol. (184), pp.971-976.

Google Scholar
