Design of Artificial Hip Joint by Carbon/PEEK Composites

Abstract:

The purpose of this study is to determine the correct estimation of the various designs for artificial hip joint of the Carbon/PEEK composites. Validity of the study has been tested with the alternative materials for the metal-based materials for artificial hip joint. Moreover, this work evaluated the FEA according to the fiber ply orientation and the condition of load. The stem shape of two kinds was designed through the normal shape of the femur. Three load cases of 1kN, 2.5kN and 5kN were used for each of FEA model. In the case of general shape, the results by ply configuration showed that the stress of ply configuration I was lower compared to ply configuration II and III. On the other hand, in the case of curved shape, ply configuration II were lower compared to ply configuration I and III. The result was checked that the stress of curved shape was higher than that of the general shape in the load of 2.5kN. It could be confirmed then that a similar phenomenon would occur in the condition of 5kN load. However, in the case of ply configuration II, the stress of the curved shape was lower than the stress of the general shape.

• Periodical: Advanced Materials Research (Volumes 774-776)
• Pages: 1336-1341
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.774-776.1336
• Online since: September 2013
• Authors: Yun Hae Kim, Sung Won Yoon, Min Kyo Jung, Jin Cheol Ha, Ri Ichi Murakami
• Keywords: Carbon/PEEK Composites, Design, Finite Element Analysis (FEA), STEM

References

[1] M. U. Kim and J. R. Youn, A Study on Biomimetic Composite for Design of Artificial Hip Joint, Textile science and engineering, (2000), 211-219.

[2] H. J. Kim, Study of the development of customized hip implant in Total Hip Replacement(THR), The Graduate School Yonsei University, (2010).

[3] Ikeda M, Komatsu SY, Sowa I, and Niinomi M, Aging behavior of the Ti-29Nb-13Ta-4. 6Zr new b alloy for medical implants, Metall Mater Trans A, 33 (2002) 487–493.

DOI: 10.1007/s11661-002-0110-9

[4] Niinomi M, Recent research and development in titanium alloys for biomedical applications and healthcare goods, Sci. Technol. Adv. Mater., 4 (2003) 445–454.

[5] Bania PJ, Lenning GA, and Hall JA, Development and properties of Ti-15V-3Al-3Sn-3Cr. In: Boyer RR, Rosenberg HW, editors. b Titanium Alloys in the 1980's. Warrendale, PA: AIME; (1984) 209–229.

[6] Kamachi Mudali U, Sridhar TM and Baldev R, Corrosion of bioimplants. Sadhana 28 (2003) 601–637.

[7] H. Bougherara, M. Bureau, M. Campbell, A. Vadean and L. Yahia, Design of a biomimetic polymer-composite hip prosthesis, Wiley InterScience, (2007) 27-40.

DOI: 10.1002/jbm.a.31146

[8] T. Kawamura, M. Zako, T. Kurashiki, H. Nakai, T Furuta, N. Sugano, H. Yoshikawa and S. Bandoh, On a Design Method of Composites Stem Based on CT Images, International Conference on Composite Materials, (2007) 1-10.
