An On-Going Monitoring Project of a New Timber Structure

Abstract:

Structural design, regardless of construction material, is based mainly on deterministic codes that partially take into account the real structural response under service and environmental conditions. This approach can lead to overdesigned (and expensive) structures. The differences between the designed and the real behaviors are usually due to service loads not taken into account during the design or simply to the natural degradation of materials properties with time. This is particularly true for wood, which is strongly influenced by service and environmental conditions. Structural Health Monitoring can improve the knowledge of timber structures under service conditions, provide information on material aging and follow the degradation of the overall building performance with time.A long-term monitoring control has been planned on a three-floor structure composed by wooden trusses and composite concrete-wood slabs. The structure is located in Nantes, France, and it is the new extension to the Wood Science and Technology Academy (ESB). The main purpose of the monitoring is to follow the long-term structural response from a mechanical and energetic point of view, particularly during the first few service years. Both static and dynamic behavior is being followed through strain gages and accelerometers. The measurements will be further put into relation with the environmental changes, temperature and humidity in particular, and with the operational charges with the aim to improve the comprehension of long-term performances of wooden structures under service. The goal is to propose new improved and optimized methods to make timber constructions more efficient compared to other construction materials (masonry, concrete, steel).The paper will mainly focus on the criteria used to design the architecture of the monitoring system, the parameters to measure and the sensors to install. The first analyses of the measurements will be presented at the conference to have a feedback on the performance of the installed sensors and to start to define a general protocol for the Structural Health Monitoring of such type of timber structures.

• Periodical: Advanced Materials Research (Volume 778)
• Pages: 757-764
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.778.757
• Online since: September 2013
• Authors: Francesca Lanata
• Keywords: In-Service Behavior, Strain Gages, Structural Health Monitoring (SHM), Timber Structure

References

[1] EN1990 Eurocode 0: Basis of structural design.

[2] P. Dietsch, J. Köhler, Assessment of timber structures, Shaker Publ. Company, Germany, (2010).

[3] G. López, L.A. Basterra, L. Acuña, Estimation of wood density using infrared thermography, J. Constr. Building Mat. 42 (2013) 29–32.

DOI: 10.1016/j.conbuildmat.2013.01.001

[4] A. Nair, C. S. Cai, S. Hou, L. Deng, and X. Miao, Performance Evaluation of a FRP‐Wrapped Balsa Wood Bridge Deck System, in: ASCE, 12th International Conference on Engineering, Science, Construction and Operations in Challenging Environments, Honolulu, 2010, pp.1693-1702.

DOI: 10.1061/41096(366)153

[5] M. Zanetti, T.G. Rials, D. Rammer, NIR-monitoring of in-service wood structures, in: ASCE, Structures Congress and the Forensic Engineering Symposium, 2005, New York.

DOI: 10.1061/40753(171)40

[6] M. Kisternaya, V. Kozlov, Wood science approach for the preservation of historic timber structures, in: International Conference on Wooden Cultural Heritage, Hamburg, 2009, pp.7-10.

[7] T. Isaksson, S. Thelandersson, Experimental investigation on the effect of detail design on wood moisture content in outdoor above ground applications, Building & Environment 59 (2013) 239-249.

DOI: 10.1016/j.buildenv.2012.08.023

[8] Y. Hayashi, M. Miyamto, A. Nii, et al, Structural Health Monitoring of huge traditional timber structure in Japan, in: 2nd International Conference on Structural Health Monitoring of Intelligent Infrastructure, 2005, pp.1043-1048.

[9] F.C. Choi, J. Li, B. Samali, K. Crews, Application of the modified damage index method to timber beams, Engineering Structures 30 (2008) 1124–1145.

DOI: 10.1016/j.engstruct.2007.07.014

[10] H. Morris, M. Worth, P. Omenzetter, Monitoring modern timber structures and connections, in: International Conference on Structural Health Assessment of Timber Structures, Lisbon, (2011).

[11] C. Dudescu, M. Somotecan, M. Hardau, Aspects related direct application of strain gages on wood, Annals of DAAAM & Proceedings, (2009).

[12] S. Boulet, Caractérisation du confort hygrothermique et acoustique dans les constructions à base de bois, PhD thesis, Chambéry, (2009).
