Influences of Machining Parameters on Electrode Wear in Piezoelectric Self-Adaptive Micro-EDM

Abstract:

To resolve such problems as higher electrode wear and low machining efficiency of micro-EDM, a new piezoelectric self-adaptive micro electrical discharge machining system (PSMEDM), based on inverse piezoelectric effect, was developed in this paper. In this new system, a piezoelectric actuator with high frequency response was applied as the micro feeding system to regulate the discharge gap. The machining mechanism and machining process were elaborated. The paper focus on the planning of PSMEDM process and the electrode wear problem. Special attention is paid on the influence of machining parameters such as open voltage, capacitance, resistance, spindle rotational speed and initial feed speed on machining efficiency by using signal to noise analysis method based on orthogonal experiment.

• Periodical: Advanced Materials Research (Volume 787)
• Pages: 588-593
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.787.588
• Online since: September 2013
• Authors: Xiu Zhuo Fu, Li Ying Gao, Qin He Zhang
• Keywords: Electrode Wear, Micro-EDM, Piezoelectric Actuator, Taguchi Method

References

[1] Yu Z Y, Rajurkar K P, Shen H. High Aspect Ratio and Complex Shaped Blind Micro Holes by Micro EDM. CIRP Annals-Manufacturing Technology, 2002, 51: 359-362.

DOI: 10.1016/s0007-8506(07)61536-4

[2] Yong Li, Min Guo, Zhaoying Zhou, etc. Micro electro discharge machine with an inchworm type of micro feed mechanism. Journal of the International Societies for Precision Engineering and Nanotechnology. 2002(26): 7-14.

DOI: 10.1016/s0141-6359(01)00088-5

[3] Eberhard Bamberg, Sumet Heamawatanachai. Orbital electrode actuation to improve efficiency of driiling micro-holes by micro-EDM. Journal of materials processing technology. 2009, 209: 1826-1834.

DOI: 10.1016/j.jmatprotec.2008.04.044

[4] Hung Sung Liu, Biing Hwa Yan, Chien Liang Chenia, etc. Application of micro-EDM combined with high-frequency dither grinding to micro-hole machining. International Journal of Machine Tools & Manufacuture. 2006, 46: 80-87.

DOI: 10.1016/j.ijmachtools.2005.03.017

[5] J.L. Lin, K. S. Wang, B.H. Yan, etc. optimization of the electrical discharge machining process based on the Taguchi method with fuzzy logics. Journal of Materials Processing Technology. 2000, 102: 48-55.

DOI: 10.1016/s0924-0136(00)00438-6

[6] Yan-Cheng Lin, Yuan-Feng Chen, Der-An Wang, etc. optimization of machining parameters in magnetic force assisted EDM based on Taguchi method. Journal of Materials Processing Technology. (2008).

DOI: 10.1016/j.jmatprotec.2008.07.052

[7] Lung Kwang pan, Che Chung Wang, Shien Long Wei, etc. Optimizing multiple quality characteristics via Taguchi method-based grey analysis. Journal of Materials Processing Technology. 2007, 182: 107-116.

DOI: 10.1016/j.jmatprotec.2006.07.015
