Beam Frame Supported Shear Wall Structure Based on the ANSYS Finite Element Static Analysis of Beam-Type Transfer Floor

Abstract:

This article research frame supported shear wall structure Beam-type Transfer layer at the supporting wall (across full) shape and the supporting column two structure forms, in the same form of vertical uniformly distributed load, the stress distribution variation trend and characteristics of the analyzed and discussed. Using large-scale finite element analysis software ANSYS to two different Beam-type Transfer structure of the nonlinear simulation analysis, combined with the stress nephogram of X to the analysis of two kinds of structure forms of the transfer beam and upper wall and the frame work characteristics ^[. The results of the study show that: In terms of the vertical stress, wall shape across the full shear wall in the stress of the beam structure performance is better, Column will produce large stress in the beam. Shear wall and stress of the transfer beam work together to transform beam has a great influence.

• Periodical: Advanced Materials Research (Volume 788)
• Pages: 508-510
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.788.508
• Online since: September 2013
• Authors: Xing Hua Cheng, Fu Ma
• Keywords: Beam-Type Transfer Layer, Finite Element Static Analysis, Frame-Supported Shear Wall Structure

References

[1] Structural design and construction of high-rise building conversion layers Tang Xing rong by China building industry press, Beijing, 2006).

[2] Wang Xinmin. ANSYS numerical analysis of engineering structure [M]. (people's traffic press, Beijing, 2007).

[3] Hao Wenhua. Civil engineering ANSYS applications [M]. (China water conservancy and hydropower press, Beijing, 2005).
