Cu₂S and AlN Precipitates in Fe-3%Si-0.5%Cu Steel Produced by Low Slab Reheating Technique

Abstract:

The grain oriented silicon steel containing 3%Si-0.5%Cu was produced by low slab reheating temperature technique. The precipitates were observed during the mainly process such as hot rolling, normalization, primary and secondary recrystallization annealing. The species, size, density and shape of precipitates were identified using TEM technique. The results indicate that Cu₂S and AlN are mainly inhibitors which precipitate during hot rolling and normalization respectively. After primary recrystallization annealing the precipitation size of Cu₂S is in the range of 30~40nm while the mean size of AlN is ~50nm, which could inhibit grain growth. In addition, the precipitation of MnS is inhibited comparing with the precipitation of Cu₂S.

• Periodical: Advanced Materials Research (Volume 790)
• Pages: 69-72
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.790.69
• Online since: September 2013
• Authors: Yang Wang, Yun Bo Xu, Yuan Xiang Zhang, Feng Fang, Xiang Lu, Yong Mei Yu, Guo Dong Wang
• Keywords: Aluminum Nitride (AlN), Cu₂S, Grain-Oriented Silicon Steel, Precipitate

References

[1] T.J. Kumamo, T. Haratani, and Y. Ushigami: ISIJ. International Vol. 42 (2002), pp.440-449.

[2] K. Jenkins, M. Lindenmo: JMMM. Vol. 320(2008) , pp.2423-2429.

[3] G.S. Choi, C.S. Lee, J.S. Woo, B.D. Hong, U.S. Patent 5, 653, 821. (1997).

[4] G.B. Li, P.J. Zhang, Y.J. Yang, K. Y, Shen, Z.C. Hu, U.S. Patent 52012000262A1, (2012).

[5] C.S. Lee, C.H. Han, J.S. Woo, G.S. Choi, J.K. Kim, B.D. Hong, U.S. Patent 6, 451, 128. (2002).

[6] Z.Z. Liu, Y. Kobayashi, Y. Nagai: ISIJ International vol. 44 (2004), pp.1560-1567.
