Over-Voltage Suppression of Electric Railway Articulated Neutral Insulator

Abstract:

The mechanism of over-voltage is analyzed according to the problems that insulated equipment is breakdown and threat to traffic safety when locomotive goes through overlapping electrical sectioning device which generate over-voltage. The model of overlapping electrical sectioning device is established by using PSCAD software. By comparing the size of overvoltage when locomotive goes through seven and eight-span overlapping electrical sectioning device, and RC protection devices is installed in seven-span overlapping electrical sectioning device .It can be introduced : inhibitory effect is significant by installing RC protection devices in the neutral line for over-voltage . Inhibitory effect will be more obvious by installing RC protection devices in the neutral line for over-voltage compared to seven-span overlapping electrical sectioning device.

• Periodical: Advanced Materials Research (Volumes 791-793)
• Pages: 1837-1840
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.791-793.1837
• Online since: September 2013
• Authors: Zhi Jian Qu, Yu Xin Liu, Min Zhou, Jun Jun Jiang, Li Liu
• Keywords: Electric Railway, Electrical Sectioning, Inhibitory, Neutral Line, Over-Voltage

References

[1] TAN Xiubing, LIU Xiangyang. The traction power supply system of AC electrified railway[M]. Chengdu: Southwest Jiaotong University Press, (2002).

[2] FU Qiang. Overlapping electrical sectioning device of OCS[J]. Electric Railway, 2005(2): 30-32.

[3] ZHU Xuehui, CHEN Yuquan, ZHANG Hunian et al. Causes of burn-out of articulated phase breaker cable and its prevention measures[J] . Electric Railway, 2007(4): 32-35.

[4] Zhao Xiaole, Zhang Xian, Li Xiaolei. Preliminary Discussion on the Technology about Catenary on Three Fracture Overlapping Electrical Sectioning Device. Railway Construction Technology, 2010(7): 22-29.

[5] Gong Yansheng. Research of Over-voltages of Electric Locomotive Passing the Articulated Phase Insulator[J]. (2008).
