Numerical Simulation of Filling and Solidification in Sand Casting by Procast

Abstract:

At present, pulley produced in China has been able to meet the demand of domestic and international markets. But there are many problem of the pulley industry in our country, such as too many production enterprises and the low level of export products. And as components of drive system are light weight and raw material price of pulley casting are rising, manufacturing requirements of the pulley are also more and more high. Aiming at the casting defects of pulley that enterprise current product, pulley casting blank model of common material HT250 be made by three-dimension software, numerical simulation of filling and solidification process for pulley sand casting by the casting simulation software Procast, the size and location of the various casting defects were forecasted and analyzed, reflecting the pulley filling and solidification process of the actual situation, due to the thicker pulley rim and less heat dissipation, position of shrinkage is close to the middle of rim [, a method of eliminating defects is proposed to realize sequential solidification, and thus to minimize porosity shrinkage and improve casting performance and reduce casting time and reduce production costs.

• Periodical: Advanced Materials Research (Volumes 791-793)
• Pages: 550-553
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.791-793.550
• Online since: September 2013
• Authors: Dong Dong Han, Cheng Jun Wang, Juan Chang, Lei Chen, Huai Bei Xie
• Keywords: Numerical Simulation, Procast, Pulley, Sand Casting

References

[1] J. Lu, G.M. Peng, R.G. Zhao. Analysis on Shrinkage Hole and Shrinkage Porosity Defect of V type Belt Wheel and Its Process Research[J]. Hot Working Technology, 2012, (41): 07: 205.

[2] Meton Flemins. Advanced Casting of Solidification Process of Shaped Casting[J].J. Master. Science Technology, 1995 (11): 313-322.

[3] H.R. Wang, A.M. Li, J.Y. Wang. Optimization Technological Design and Numerical Simulation of Belt Pulley on Electric Engine[J]. Hot Working Technology, 2009, (38)17: 32-33.

[4] B.R. Qin, J.F. Wang, J.T. Fan. Numerical Simulation of Filling and Solidification Process for Shredding Knife in Investment Casting[J]. Special Casting and Nonferrous Alloys, 2010, (30)6: 533.

[5] S.M. Lai. Study and Application on Numercial Simulation of Casting[J]. Shandong University of Science and Technology Master's degree thesis, 2011, (SⅠ): 43-44.

[6] Y.D. Yu, J.R. Wang, H.Y. Jiang, etc. Numerical Ssimulation of Filling and Solidification Process for Magnesium Alloy in Low Pressure Cast Process[J]. Hot Working Technology, 20051010(10): 31.
