Effect of Ultrasonic Vibration Parameters on Machining Performance Based on Tool-Workpiece Contact Ratio

Abstract:

Ultrasonic assisted turning (UAT) is an efficient cutting technique for difficult-to-cut materials. In order to study the effect of vibration parameters on machining performance, tool-workpiece contact ratio (TWCR) was defined. A finite element model for ultrasonic assisted turning of Ti-6Al-4V was established. Effects of tool vibration frequency, tool vibration amplitude and workpiece cutting speed on cutting force and cutting temperature were analyzed. It is observed that both the increase in the tool vibration parameters and the decrease in the cutting speed reduce the TWCR, which in turn reduces both cutting forces and cutting temperature. By using the finite element model the appropriate tool vibration frequency, tool vibration amplitude and cutting speed can be obtained.

• Periodical: Advanced Materials Research (Volume 797)
• Pages: 332-337
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.797.332
• Online since: September 2013
• Authors: Dong Lu, Qiang Wang, Yong Bo Wu, Hong Аu Huang
• Keywords: Cutting Force, Optimization, Tool-Workpiece Contact Ratio, Ultrasonic Vibration Cutting

References

[1] Ahmed N, Mitrofanov, A V, Babitsky V I, et al. 3D finite element analysis of ultrasonically assisted turning[J]. Computational Materials Science, 2007, 39: 149-154.

DOI: 10.1016/j.commatsci.2005.12.045

[2] Nath C, Rahman M. Effect of machining parameters in ultrasonic vibration cutting[J]. International Journal of Machine Tools & Manufacture, 2008, 48: 965-974.

DOI: 10.1016/j.ijmachtools.2008.01.013

[3] Amini S, Soleimanimehr H, Nategh, M J, et al. FEM analysis of ultrasonic-vibration-assisted turning and the vibratory tool[J]. Journal of Materials Processing Technology, 2008, 201: 43-47.

DOI: 10.1016/j.jmatprotec.2007.11.271

[4] Zhou M, Ngoi B K A, Yusoff M N, et al. Tool wear and surface finish in diamond cutting of optical glass. Journal of Materials Processing Technology, 2006, 174: 29-33.

DOI: 10.1016/j.jmatprotec.2005.02.248

[5] Soutome T, Sato K. Study on ultrasonic vibration cutting (1st report): -fundamental analysis and experimental consideration of vibration cutting mechanism on thrust force direction[J]. Journal of the Japan Society for Precision Engineering, 2011, 77: 559-565.

[6] Harada K, Sasahara H. Effect of dynamic response displacement/stress amplitude on ultrasonic vibration cutting[J]. Journal of Materials Processing Technology, 2009, 209(9): 4490-4495.

DOI: 10.1016/j.jmatprotec.2008.10.026

[7] Marusich T D, Ortiz M. Modeling and simulation of high speed machining[J]. International Journal for Numerical Methods in Engineering, 1995, 126: 3675-3694.

DOI: 10.1002/nme.1620382108

[8] Yamazaki T, Tsuchiya k, Sato U. Ultrasonic vibration cutting of Ti-6Al-4V alloy[J]. Japan Institute of Light Metals, 2007, 57: 152-156.

DOI: 10.2464/jilm.57.152
