Effect of Contact Stiffness of Grinding Wheel on Ground Surface Roughness and Residual Stock Removal of Workpiece

Abstract:

In the grinding operation, grinding wheels are deformed by grinding forces, so that residual stock removal of the workpiece takes place. Since this residual stock removal of the workpiece causes low machining efficiency and deterioration of machining accuracy, high hardness grinding wheels may be selected in order to obtain high machining efficiency and/or high quality machining accuracy. On the other hand, when grinding operations used by low hardness grinding wheels are carried out, it is well known that ground surface roughness is smaller than in case of higher hardness grinding wheels. From such a viewpoint, this study aims to investigate experimentally the effect of the contact stiffness of grinding wheel on the ground surface roughness and the residual stock removal of the workpiece. Grinding operations were carried out using three grinding wheels which are different hardness type, and ground surface roughness and residual stock removal of the workpiece were measured. The contact stiffness of grinding wheel was calculated by a support stiffness of single abrasive grain and a contact area between grinding wheel and workpiece. Comparing the contact stiffness of grinding wheel with the ground surface roughness and the residual stock removal of the workpiece, it was known that ground surface roughness increases and residual stock removal of workpiece decreases with increaseing the contact stiffness of grinding wheel. From these results, since elastic deformation of the grinding wheel changed depending on the suppot stiffness of single abrasive grain, it was clarified that the ground surface roughness and the residual stock removal of the workpiece were changed by the contact stiffness of grinding wheel.

• Periodical: Advanced Materials Research (Volume 797)
• Pages: 522-527
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.797.522
• Online since: September 2013
• Authors: Taisei Yamada, Hwa Soo Lee, Kohichi Miura
• Keywords: Contact Stiffness, Depth of Cut, Elastic Deformation, Grinding Wheel, Surface Roughness (SR)

References

[1] Yasuo SAKAI, Hukuzo YAGISHITA and Yuji FURUKAWA: Study on the Simulation of Grinding Process (3rd Report), Journal of the Japan Society for Precision Engineering, Vol. 62, No. 12, (1996), pp.1778-1782.

DOI: 10.2493/jjspe.62.1778

[2] Takazo YAMADA, Michael MORGAN, Hwa-Soo LEE and Kohichi MIURA: Calculation of the Contact Stiffness of Grinding Wheel, Advanced Materials Research Vol. 325 (2011) pp.54-59.

DOI: 10.4028/www.scientific.net/amr.325.54

[3] Takazo YAMADA, Michael MORGAN, Hwa-Soo LEE and Kohichi MIURA: Calculation of Effective Ground Depth of Cut by Means of Grinding Process Model, Key Engineering Materials, Vol. 496(2012), PP. 7-12.

DOI: 10.4028/www.scientific.net/kem.496.7

[4] Takazo YAMADA, Hwa-Soo LEE and Kohichi MIURA: Quantitative estimation of abrasive grain behavior and elastic recovery of workpiece in grinding operation, Journal of the Japan Society for Abrasive Technology, Vol. 55, No. 12 (2011), pp.723-728.

[5] Handbook of Precision Machining, (in Japanese), Corona Publishing, (1992), p.306.
