Study of Grinding Force for Internal Cylinder of Ultrasonic ELID Composite Grinding

Abstract:

In order to reveal the theoretical nature of ultrasonic ELID composite grinding which is an efficient grinding technology, this paper theoretically analyzes a single grains motion characteristics in the process of internal cylindrical grinding under axial vibration and established a single grits kinematic equation. Then the grits trajectory is draw by matlab, and the contact length of the grinding wheel and the workpiece is achieved. At the same time the electrolysis parameters are introduced into the dynamic number of effective grits with analysis its electrochemical action. Thereby a force model for the ultrasonic ELID composite internal cylindrical grinding is established. Through analysis the model it is easy to find the force is fluctuated periodically with electrical current changing.

• Periodical: Advanced Materials Research (Volume 797)
• Pages: 733-739
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.797.733
• Online since: September 2013
• Authors: Bo Zhao, Ya Min Li, Ping Yan Bian
• Keywords: Axial Vibration, Grinding Force, Internal Cylindrical Grinding, Model

References

[1] Ma Chunxiang, Wang Yan, Shamoto E, Moriwaki T. Influence of ultrasonic vibration diamond tool on the critical depth of cut of brittle materials [J]. Chinese Journal of Mechnical Engineering. Vol. 41-6 (2005), pp.198-202.

DOI: 10.3901/jme.2005.06.198

[2] E. Uhlmann.,G. Spur. Surface Formation in Creep Feed Grinding of Advanced Ceramics with and without Ultrasonic [J]. Assistance. Annals of the CIRP. Vol. 47-1(1998), pp.249-252.

DOI: 10.1016/s0007-8506(07)62828-5

[3] Kei Harada, Hiroyuki Sasahara. Effect of dynamic response and displacement/stress amplitude on ultrasonic vibration cutting [J]. Journal of Materials Processing Technology . Vol. 209 (2009), pp.4490-4495.

DOI: 10.1016/j.jmatprotec.2008.10.026

[4] M.J. Nategh, H. Razavi, A. Abdullah. Analytical modeling and experimental investigation of ultrasonic-vibration assisted oblique turning, part I: Kinematics analysis [J]. International Journal of Mechanical Sciences . Vol. 63 (2012) , pp.1-11.

DOI: 10.1016/j.ijmecsci.2012.04.007

[5] Indraneel Biswas·A. Senthil Kumar·Musrafizur Rahman. Experimental study of wheel wear in electrolyric in-process dressing and grinding [J]. Int J Adv Manuf Technol . Vol. 50(2010), pp.931-940.

DOI: 10.1007/s00170-010-2589-3

[6] Tanveer Saleh·Indraneel Bishwas·Mustafizur Rahman. Efficient dressing of the wheel in ELID grinding by controllable voltage with force feed back [J]. Int J Adv Manuf Technol . Vol. 46 (2010), pp.123-130.

DOI: 10.1007/s00170-009-2076-x

[7] Kaifei ZHANG, Chengzu Ren, Lijian Yang. Precision internal grinding of bearing steel based on the state control of oxide layer with electrolytic in-process dressing[J]. Journal of Materials Processing Technology. Vol. 212 (2012) , pp.1611-1621.

DOI: 10.1016/j.jmatprotec.2012.02.018

[8] Ren Jingxin, Hua Dingan. Grinding Theory[M]. Northwestern Polytechnical University published. (1988).
