Visualization of 3D Topography of Grinding Wheel Surface Dressed by Rotary Diamond Dresser

Abstract:

A computer-aided simulation was developed to visualize the three-dimensional topography of a grinding wheel surface dressed by a rotary diamond dresser (RDD), and the effects of up-cut and down-cut dressing on the roughness of the dressed surface were examined to demonstrate the effectiveness of the simulation. In the case of single-pass dressing, the roughness of the grinding wheel surface decreased with decreasing dresser feed rate and approached a constant value depending on the velocity ratio of the RDD to the grinding wheel. In the case of multipass dressing, up-cut dressing provided the grinding wheel with a surface topography which was much more stable than that provided by down-cut dressing.

• Periodical: Advanced Materials Research (Volume 797)
• Pages: 751-756
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.797.751
• Online since: September 2013
• Authors: Akihiko Kubo, M.A.K. Chowdhury, Shoma Noda, Junichi Tamaki, A.M.M. Sharif Ullah
• Keywords: Computer-Aided Simulation, Multipass Dressing, Rotary Diamond Dresser, Single-Pass Dressing, Surface Topography of Grinding Wheel

References

[1] S. Moritomo, M. Ota and K. Uchiyama: Proceedings of the Annual Meeting of the JSPE (1984), p.471.

[2] M. Yokogawa, Y. Furukawa, T. Imai and K. Unno: Proceedings of the Autumn Meeting of the JSPE (1990), p.411.

[3] Z. M. Bzymek, G. M. Duzy and R. B. J. Mindek, Key Engineering Materials, Vol. 389-390 (2009), p.362.

DOI: 10.4028/www.scientific.net/kem.389-390.362

[4] A. Kubo, M. A. K. Chowdhury, J. Tamaki and A. M. M. Sharif Ullah: Proceedings of the Annual Meeting of the JSAT (2012), p.24.
