A Visualization Study of the Radial-Mode Abrasive Waterjet Turning Process for Alumina Ceramics

Abstract:

A visualization study of the radial-mode abrasive waterjet (AWJ) turning process on an alumina ceramic is presented to gain an understanding of cutting front development process and hence the material removal mechanisms. A statistically designed experiment is conducted to study the effects of process parameters on the development of the cutting front, considering the change of water pressure, nozzle feed speed and nozzle tilt angle. It is found that the most significant parameters affecting the cutting front development are feed speed and water pressure. Further, the actual jet impact angle is dependent on both the water pressure and feed speed, but at higher water pressures the actual impact angle tends to become independent of feed speed, while water pressure becomes the dominating factor.

• Periodical: Advanced Materials Research (Volume 797)
• Pages: 9-14
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.797.9
• Online since: September 2013
• Authors: Mirza Ahmed Ali, Jing Ming Fan, Hong Tao Zhu, Jun Wang
• Keywords: Abrasive Waterjet Turning, Ceramic, Turning Process, Visualization

References

[1] J. Wang: Waterjet Machining of Engineering Materials: Trans Tech Publications, Uetikon-Zuerich, Switzerland, (2003).

[2] J. Wang: Predictive depth of jet penetration models for abrasive waterjet cutting of alumina ceramics, International Journal of Mechanical Sciences, Vol. 49 (2007), pp.306-316.

DOI: 10.1016/j.ijmecsci.2006.09.005

[3] M. Hashish, M. Ramulu, S. Kunaporn and P. Posinasetti: Abrasive waterjet machining of aerospace materials. In: 33rd International SAMPE Proceedings, Vol. 33, 2001, pp.1340-1354.

[4] J. Wang: Abrasive waterjet machining of polymer matrix composites-cutting performance, erosive process and predictive models. International Journal of Advanced Manufacturing Technology, Vol 15 (1999), pp.757-768.

DOI: 10.1007/s001700050129

[5] D.K. Shanmugam, T. Nguyen and J. Wang: A study of delamination on graphite/epoxy composites in abrasive waterjet machining. Composites: Part A, Vol. 39 (2008), pp.923-929.

DOI: 10.1016/j.compositesa.2008.04.001

[6] M. Hashish: Turning with abrasive-waterjets-A first investigation, Journal of Engineering for Industry, Vol. 109 (1987), pp.281-290.

DOI: 10.1115/1.3187130

[7] A. Ansari, M. Hashish and M. Ohadi: Flow visualization study of the macromechanics of abrasive-waterjet turning, Experimental Mechanics, Vol. 32 (1992), pp.358-364.

DOI: 10.1007/bf02325589

[8] R. Manu and N. R. Babu: Influence of jet impact angle on part geometry in abrasive waterjet turning of aluminium alloys, International Journal of Machining and Machinability of Materials, Vol. 3 (2008), pp.120-132.

DOI: 10.1504/ijmmm.2008.017629

[9] R. Manu and N. R. Babu: An erosion-based model for abrasive waterjet turning of ductile materials, Wear, Vol. 266 (2009), pp.1091-1097.

DOI: 10.1016/j.wear.2009.02.008

[10] I. Zohourkari and M. Zohoor: An erosion-based modelling of abrasive waterjet turning. World Academy of Science, Engineering and Technology, Vol 38 (2010): pp.359-363.

[11] Z.W. Zhong and Z.Z. Han: Turning of glass with abrasive waterjet, Materials and Manufacturing Processes, Vol. 17 (2002), pp.339-349.

DOI: 10.1081/amp-120005380

[12] W.Y. Li, J. Wang and Y.M. Ali, An experimental study of radial-mode abrasive waterjet turning of steels, Materials Science Forum, Vol. 697-698 (2012), pp.166-170.

DOI: 10.4028/www.scientific.net/msf.697-698.166

[13] J. Wang, T. Nguyen and K.L. Pang: Mechanisms of microhole formation on glasses by an abrasive slurry jet, Journal of Applied Physics, Vol. 105(4) (2009), 044906.

DOI: 10.1063/1.3079802
