Three-Dimensional Numerical Simulation of Fluid with Sparse Particles' Erosion to Pipelines

Abstract:

A three dimensional fluid flow model was set up in this paper, based on the computational fluid dynamics (CFD) and the elasticity theory. Using the finite volume method, a 120° bend was taken as a research object to simulate the erosion to the wall of fluid with sparse particles, finally, to determine the most severe wear areas.At the same time, the distribution of two-phase flows pressure and velocity was analyzed in 45° and 90° bends, then tracked the trajectory of the particles. The results show that the 90°bend has the smallest wear area and particle distribution or combination property is the best.

• Periodical: Advanced Materials Research (Volumes 805-806)
• Pages: 1785-1789
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.805-806.1785
• Online since: September 2013
• Authors: Chang Bin Wang, Miao Wang, Xiao Xu Li, Yu Liu, Jie Nan Dong
• Keywords: Bend, Dispersed Phase, Erosion, Numerical Simulation, Particle

References

[1] Ying Ma, Jun Ren, Yuandong Li and Tijun Chen: Journal of Lanzhou University of Technology, Vol. 31 (2005), p.21 (In Chinese).

[2] Gang Dong and Jiuyuan Zhang: Journal of Materials Science & Engineering, Vol. 21 (2003), p.307 (In Chinese).

[3] Sunyi Che: Corrosion & Protection in Petrochemical Industry, Vol. 20 (2003), p.59 (In Chinese).

[4] Patankar S V: Heat transfer and fluid flow numerical calculations (1989).

[5] Haider A and Levenspiel O: Powder Technology, Vol. 58 (1989), p.63.

[6] Shaofeng Zhang and Huimin Cao: Journal of Hebei University of Technology, Vol. 35 (2012), p.57 (In Chinese).

[7] Kliafas Y: Holt M. Experiment in Fluid, Vol. 5 (1987), p.73.
