Mechanical and Thermal Properties of Rubber Toughened Carbon Black-Filled Polyester Composite

Abstract:

The influences of Carbon Black (CB) as filler for rubber toughened polyester composite on thermal properties were investigated, in consideration for applications such as automotive parts and integrated circuits (IC) encapsulations. The usage of CB as filler is one of the efforts in increasing and varying the use of rubber and unsaturated polyester thermoset in composite materials. Unsaturated polyester was mixed with 3% liquid natural rubber (LNR) as toughening agent and CB, which were varied from 0, 2, 4, 6, 8, and 10% using mechanical stirrer and moulded by using the open mould technique. Impact testing was conducted for mechanical property and it was found that the addition of CB increased the impact strength by 87%. Thermal properties of the composites were evaluated using a thermogravimetric analyzer (TGA) and differential scanning calorimetry (DSC). The TGA curves of the composites were quite similar, but there were slight increment in thermal stability for several CB filled composites compared to the neat polyester matrix. DSC analysis showed that all the composites were fully cured, and CB filled composites had a slower heat flow rate compared to the neat rubber toughened composite.

• Periodical: Advanced Materials Research (Volume 812)
• Pages: 163-168
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.812.163
• Online since: September 2013
• Authors: Mohd Redzuan Aein Afina, Bonnia Noor Najmi, Shuhaimen Siti Shakirah, Siti Norasmah Surip
• Keywords: Carbon Black (CB), Mechanical, Polyester, Rubber Toughened, Thermal

References

[1] S. Rassmann, R. Paskaramoorthy and R.G. Reid, Effect of resin system on the mechanical properties and water absorption of kenaf fibre reinforced laminates, Materials and Design Vol. 32 (2011), p.1399–1406.

DOI: 10.1016/j.matdes.2010.09.006

[2] D.M.A. Farias, M.Z. Farina, A.P.T. Pezzin and D.A.K. Silva, Unsaturated polyester reinforced with fiber and powder of peach palm, Materials Science and Engineering Vol. 29 (2008), p.510–513.

DOI: 10.1016/j.msec.2008.09.020

[3] Y.P. Lee, H.S. Ahmad, R. Rasid, Y.E.N. Se, H.K. Yew and M.A. Tarawneh, Effects of liquid natural rubber (LNR) on the mechanical properties of LNR toughened epoxy composite, Sains Malaysiana Vol. 40(7) (2011), p.679–683.

[4] H. Ismail and A. Suryadiansyah, Effects of filler loading on properties of polypropylene–natural rubber–recycle rubber powder (PP-NR-RPP) composites, Journal of Reinforced Plastics & Composites Vol. 23(6) (2004), p.639–650.

DOI: 10.1177/0731684404032869

[5] H.Y. Li, H.Z. Chen, W.J. Xu, F. Yuan, J.R. Wang and W. M. Mang, Polymer-encapsulated hydrophilic carbon black nanoparticles free from aggregation, colloids and surfaces A: physicochem, Eng. Aspects Vol. 254 (2005), p.173–178.

DOI: 10.1016/j.colsurfa.2004.12.002

[6] J.S. Tan, and N.A.F.N. Farid, Carbon molecular sieves produced from oil palm shell for air separation, Separation and Purification Technology Vol. 35 (2004), p.47–54.

DOI: 10.1016/s1383-5866(03)00115-1

[7] J.M. Degrange, M. Thominea, Ph. Kapsa, J.M. Pelletier, L. Chazeau, G. Vigier, G. Dudragne and L. Guerbe, Short Communication: Influence of viscoelasticity on the tribological behaviour of carbon black filled nitrile rubber (NBR) for lip seal application, Wear Vol. 259 (2005), p.684–692.

DOI: 10.1016/j.wear.2005.02.110

[8] N. Chand and A. Nigrawal, Development, dielectric, and thermal studies on HAF carbon-filled polyester gradient composites, Journal of Composite Materials. 43 (2009) 2859-2869.

DOI: 10.1177/0021998309345297

[9] N.S.M. El-Tayeb, A study on the potential of sugarcane fibers/polyester composite for tribological applications, Wear Vol. 265 (2007), pp.223-235.

DOI: 10.1016/j.wear.2007.10.006

[10] M.L. Auad, P.M. Frontini, J. Borrajo and M.I. Aranguren, Liquid rubber modified vinyl ester resins, liquid rubber modified vinyl ester resins : fracture and mechanical behaviour, Polymer Vol. 42 (2000), pp.372-373.

DOI: 10.1016/s0032-3861(00)00773-4

[11] A.H.P.S. Khalil, P. Firoozian, I.O. Bakare, M.H. Akil and M.A. Noor, Exploring biomass based carbon black as filler in epoxy composites: flexural and thermal properties, Materials and Design Vol. 31 (2010), pp.3419-3425.

DOI: 10.1016/j.matdes.2010.01.044

[12] R.V. Silva, D. Spinelli, F.W.W. Bose, N.S. Claro, G.O. Chierice and J.R. Tarpani, Fracture toughness of natural fibers/castor oil polyurethane composites, Compos. Sci. Techno. Vol. 66(10) (2006), pp.1328-35.

DOI: 10.1016/j.compscitech.2005.10.012

[13] R. Thomas, Y. Ding, Y. He, L. Yang, P. Moldenaers, W. Yang, T. Czigany, and S. Thomas, Miscibility, morphology, thermal and mechanical properties of a DGEBA based epoxy resin toughened with a liquid rubber polymer. 49 (2008) 278-294.

DOI: 10.1016/j.polymer.2007.11.030

[14] P. Firoozian, H.P.S.A. Khalil, H.M. Akil and A.M. Noor, Influences and properties of various activated carbon and carbon black filled in epoxy composite, Advanced Materials Research. Vol.264-265 (2011), pp.513-517.

DOI: 10.4028/www.scientific.net/amr.264-265.513

[15] C. Yu and C. Wei, Mechanical and tribological properties of phenol formaldehyde resin reinforced with nano-silica, Advanced Materials Research Vol. 194-196 (2011), pp.1772-1775.

DOI: 10.4028/www.scientific.net/amr.194-196.1772

[16] A. Khalil, N.Z. Noriman, M.N. Ahmad, M.M. Ratnam and N.A.N. Fuaad, Polyester composite filled carbon black and activated carbon from bamboo (gigantochloa scortechinii): physical and mechanical properties, Journal of Reinforced Plastics and Composites Vol. 26 (2007), pp.305-311.

DOI: 10.1177/0731684407065066

[17] A.H.P.S. Khalil, P. Firoozian, I.O. Bakare, M.H. Akil and M.A. Noor, Exploring biomass based carbon black as filler in epoxy composites: flexural and thermal composite, Materials and Design Vol. 31 (2010), pp.3419-3425.

DOI: 10.1016/j.matdes.2010.01.044

[18] A. Boonmahitthisud and S. Chuayjuljit, Effect of carbon black and carbon nanotube on mechanical and thermal properties of 80NR/20SBR composite, Materials Science Forum. 654-656 (2010) 2783-2786.

DOI: 10.4028/www.scientific.net/msf.654-656.2783

[19] R. Socher, B. Krause, S. Hermasch, R. Wursche and P. Potschke, Electrical and thermal properties of polyamide 12 composites with hybrid filler systems of multiwalled carbon nanotubes and carbon black, Composites Science and Technology. 71 (2011) 1053–1059.

DOI: 10.1016/j.compscitech.2011.03.004

[20] X. Wen, Y. Wang, J. Gong, J. Liu, N. Tian, Y. Wang, Z. Jiang, J. Qiu and T. Tang, Thermal and flammability properties of polypropylene/carbon black nanocomposites, Polymer Degradation and Stability Vol. 97 (2012), pp.793-801.

DOI: 10.1016/j.polymdegradstab.2012.01.031

[21] D. Wang, X. Zhao, H. Jia, X. Yu, Q. Li, L. Wang, H. Zhou, G. Dang and C. Chen, Toughening of thermosetting resins with thermoplastic polyimide: thermal, morphological and mechanical characterization, Advanced Materials Research Vols. 150-151 (2011) pp.1330-1335.

DOI: 10.4028/www.scientific.net/amr.150-151.1330
