Micro Parts Errors to Precision Manufacturing using UV-LIGA Technology

Abstract:

To remove the shortcomings from the manufacturing process it is necessary to optimize all process parameters, for all stages of technological process: the exposure, the development, the electroforming and removal of the exposed SU8. This research implies that various types of MEMS devices can be developed at a high accuracy with design flexibility, only if all process parameters are optimized. This article is presenting a study regarding typical errors arisen during manufacturing of micro-parts using UV-LIGA technology.

• Periodical: Advanced Materials Research (Volumes 816-817)
• Pages: 237-241
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.816-817.237
• Online since: September 2013
• Authors: Cristinel Ilie, C. Daniel Comeagă, Octavian G. Donţu, Marius Popa
• Keywords: Direct Writing Lithography, Fabrication Errors, Micro Machining, Microfabrication Technologies, SU8, UV-LIGA
