Error Analysis of Wide Area Measurement Based Measurement Power Flow

Abstract:

Measurement take place of calculation is an advantage of wide area measurement based measurement power flow, but its accuracy needs to be explored. This paper points out the measurement power flow’s data dose not conform to the actual power flow’s data on condition of phase angle measurement exist error. Through the analysis of example we can see that the deviation of active power will reach 15% when phase angle exist 0.1°error, its accuracy is worse than DC power flow in engineering calculation .This paper suggest using the phase angle value which was measured as initial value in power flow calculation, it will reduce the error’s impact on power flow calculation.

• Periodical: Advanced Materials Research (Volumes 816-817)
• Pages: 446-449
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.816-817.446
• Online since: September 2013
• Authors: Hai Bao, Jin Si Han, Gang Liu, Ling Wang
• Keywords: Error Analysis, Measurement Power Flow, Phase Angle Measurement, Wide-Area Measurement System (WAMS)

References

[1] HAN Jingdong: Researches and Applications of Power System Phasor and Rotor Angle Measurement Technology[D]. Nanjing: Southeast University, (2009).

[2] CHANG Naichao, LAN Zhou, GAN Deqiang and NI Yixin. A Survey on Applications of Wide-area Measurement System in Power System Analysis and Control[J]. Power System Technology, 2005, 29(10).

[3] GU Yiming: Research and development of the monitoring and management substation system for the Phasor Measurement Unit based on GPS[D]. Nanjing: Hohai University, (2006).

[4] LIN Dabin: Research of power system phasor measuring method[D]. Changsha: Hunan University, (2012).

[5] CHEN Heng. Steady-state Analysis of Power System[M]. Beijing: China Electric Power Press, (1995).

[6] Guidelines on National Electric Power Dispatching and Communication in the power system stability. PRC power industry standard, DL 755-(2001).
