Design and Implementation of Online Monitoring and Remote Diagnostic System for CNC Machine Tools

Abstract:

With the development of network technology and fault diagnosis technology, monitoring and diagnosis methods for the CNC machine tools had a great change. In this paper, an online monitoring and remote diagnosis system for CNC machine tools was built. The system was consisted of the multi-channel online acquisition system and remote fault diagnosis system. The online acquisition system achieved a real-time monitoring for CNC machine tools. The remote fault diagnosis system provided the management of devices and assistant for experts to analyze data which was uploaded from acquisition system. The system offered real-time state information of CNC machine tools and reduced downtime of machine effectively.

• Periodical: Advanced Materials Research (Volume 819)
• Pages: 136-139
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.819.136
• Online since: September 2013
• Authors: Lu Yang Jing, Wang Tai Yong, Dong Xiang Chen, Jing Xiang Fang
• Keywords: CNC Machine Tool, Fault Diagnosis, Online Monitoring

References

[1] Wang Taiyong, Jiang Yongxiang, Liu Lu, et al, Dynamic monitoring-control and intelligent diagnosis techniques for of complex manufacturing systems, Aeronautical Manufacturing Technology. 13 (2010) 27-29.

[2] Lin Jinzhou, Jiang Dayong, Geng Bo, et al, Research on the remote monitoring and fault diagnosis of CNC system based on network, 2012 2th International Conference on Functional Manufacturing and Mechanical Dynamics, China: Hangzhou. 141 (2012).

[3] Shen Aiqun, Nie Zhonghua, Xing Yan, Research on the remote online monitoring and diagnostics system of CNC machine tool, Journal of Manufacturing Automation. 25 (2003) 37-39.

[4] Ma Yutao, Ye Wenhua, Design of data Collecting System of NC Machine Based on ARM and Linux. Machinery Manufacturing and Automation. 4 (2008) 110-112.

[5] He Huilong, Wang Taiyong, Xu Yonggang, Implementation of fault diagnosis system for mechanical equipment based on internet for plant management, Journal of Jinlin University. 5 (2006) 691-695.
