Study on the Transmission Spectrum of Fiber Bragg Grating as Temperature Sensor

Abstract:

The temperature sensing characteristic of Fiber Bragg Grating (FBG) has been studied. The temperature sensing equation of FBG is revised. The accurate analysis results are obtained. The center wavelength drifts of the tested FBG are displayed in the screen of Optical Spectrum Analyzer (OSA).The experimental results show that the center wavelength of FBG is thermally red-shift with the rise of the temperature and blue-shift with the decrease of the temperature. The results are agree with the revised temperature sensing equation. It is noticed that the transmission spectrum width (SPEC-WD) of FBG fluctuates with the change of temperature. Nevertheless, the trend of the fluctuation is demonstrably towards increase, which perhaps is some potential auxiliary sensing function in future.

• Periodical: Advanced Materials Research (Volume 819)
• Pages: 197-201
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.819.197
• Online since: September 2013
• Authors: Zheng Wang, Ping Yu Zhu, Hong Qiang Liang, Wei Peng
• Keywords: Fiber Bragg Grating (FBG), Optical Spectrum Analyzer (OSA), Spectrum Width (SPEC-WD), Temperature Sensing Characteristic, Transmission Spectrum

References

[1] K.O. Hill, Y. Fujii, D.C. Johnson, et al. Photosensitivity in optical fiber waveguides: application to reflection filter fabrication. Appl. Phys. Lett, 1978, (32): 647-649.

DOI: 10.1063/1.89881

[2] G. Meltz, M.M. Morey, W.H. Glenn. Formation of Bragg gratings in optical fibers by transverse holographic method. Opt. Lett, 1989, (14): 823-825.

DOI: 10.1364/ol.14.000823

[3] K.O. Hill. Bragg gratings fabricated in mono-mode photosensitive optical fiber by UV exposure through a phase mask . Appl. Phs. Lett. 1993, (62): 1035-1037.

DOI: 10.1063/1.108786

[4] R. Gafsi, M. A . EI-Sherif. Analysis of Induced-Birefringence Effects on Fiber Bragg Gratings [J]. Opt. Fiber Technol, 2000, (6): 229-322.

DOI: 10.1006/ofte.2000.0333

[5] F. Bosiaa, J. Botsisa, M. Facchinia, et al. Deformation characteristics of composite laminates part I: speckle interferometer and embedded Bragg grating sensor measurements [J]. Composites Science and Technology, 2002, 62: 41-54.

DOI: 10.1016/s0266-3538(01)00183-x

[6] S.K. GUO, Z.K. YANG, et al. Sensing characters and experiments researches of the fiber bragg grating [J]. CHINA MEASURMENT TECHNOLOGY, 2006, 32(20: 71-73.

[7] Z. ZHOU, S.Z. TIAN, X.F. ZHAO, et al. Theoretical and experimental studies on the strain and temperature sensing performance of optical FBG [J]. Journal of functional material, 2002, 33 (5): 551-554.

[8] Y.J. ZHANG, H.B. WANG, Z.G. CHEN, W.H. BI. Study on FBG Sensor's Steel Capillary Packaging Technique and Sensing Properties [J]. LASER&INFRARED, 2009, 39(1): 53-54, 66.

[9] Y.J. RAO, Y.P. WANG, T. ZHU . Principle and application of Fiber Grating [M]. Beijing: science press, 2006. 136-140.

[10] Z.X. WU, F. WU. Fiber grating sensing principle and application [M]. Beijing: National Defense Industry Press, (2011).

[11] Otghonos, K. Kalli. Fiber Bragg Gratings Fundamentals and Applications in Telecommunications and Sensing, Artech House, 1999.

[12] M. LI, Y.B. LIAO. Optical fiber sensor and its application technology [M]. Wuhan: WU HAN University press, 2008. 8.
