The Feature Extraction Method of Gear Magnetic Memory Signal

Abstract:

Magnetic memory test technology is a new nondestructive testing technique, which is able to detect of the stress concentration area and potential fault of low speed and heavy load gear. Because the magnetic memory signals are easy to be disturbed by various sources of noises, a new method based on the intrinsic time-scale decomposition (ITD) is proposed to achieve the extraction of magnetic memory signal. Firstly, the magnetic memory signals are decomposed into several proper rotation components (PRC) and a trend component by ITD. Then reconstruct the first four order PRCs to eliminate the low frequency cyclic composition of magnetic memory signal and magnetic noise. Finally, the magnetic signal strengths of each gear tooth root are extracted using cycle average and local statistic method. The results of Experiments show that the method is suitable to pick up effective ingredients of signal to extract signal feature and has important application value in potential fault diagnosis of low speed and heavy load gearbox.

• Periodical: Advanced Materials Research (Volume 819)
• Pages: 206-211
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.819.206
• Online since: September 2013
• Authors: Yonggang Xu, Zhi Cong Xie, Lin Li Cui, Jing Wang
• Keywords: Feature Extraction, Intrinsic Time-Scale Decomposition, Metal Magnetic Memory, Potential Gear Fault, Proper Rotation Component

References

[1] Dubov A A. Express method of quality control of a spot resistance welding with usage of metal magnetic memory[J]．Welding in the World，2002, 46(6): 317-320.

[2] Doubov AA. Diagnostics of equipment and constructions strength with usage of magnetic memory[J]．Inspection Diagnostics, 2001, 35(6): 19-29.

[3] Zhang Weimin, Dong Shaoping. State-of-the-art of metal magnetic memory testing technique[J]. China Mechanical Engineering, 2003, 14(10): 892-896(in Chinese).

[4] Tang Dedong, Zhou Peng. Research on device for inspection of defects of metal structures[J]. Chinese Journal of Scientific Instrument, 2005, 25(4): 254-256 (in Chinese).

[5] Wen Wei-gang, Sa Shu-li. Mechanism and implementation of magnetic memory metal diagnostic technique [J]．Journal of Northern Jiaotong University, 2002，26(4): 67-70(in Chinese).

[6] Mark G Frei and Ivan Osorio. Intrinsic time-scale decomposition: time-frequency-energy analysis and realtime filtering of non-stationary signals[J]．Proceedings of the Royal Society A, 2007, 463: 321-342.

DOI: 10.1098/rspa.2006.1761
