The Dynamic Analysis of Gantry Crane Girder under Lifting Process

Abstract:

In order to get the displacement response curve of the Gantry Crane Girder under three stage of lifting process, the vibration differential equation and displacement response expression were deduced, combining with the actual case, the displacement response expression and displacement response curve were deduced in the load duration time 0.8 s and 0.2 s. The results show that: the lifting process is an important factor affecting the structural vibration; Displacement peak and load duration time are inversely proportional; Increase the load duration time can reduce the vibration of the structure.

• Periodical: Advanced Materials Research (Volume 823)
• Pages: 29-32
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.823.29
• Online since: October 2013
• Authors: Cheng Zhong He, Wei Liang Chen
• Keywords: Displacement Response, Gantry Crane, Lifting Dynamic Load Coefficient, Vibration System

References

[1] ShuZhen Wang. Large gantry crane girder structure dynamic optimization design method research [D]. Wuhan university of technology, (2009).

[2] Wei Guan. Based on multi-body dynamics of the whole ground crane dynamic simulation [D]. Dalian university of technology, (2011).

[3] JiYuan Zhang, HuaiMao Zhong. Quayside container crane dynamic load coefficient dynamics model and its solution [J]. Journal of Shanghai maritime university, 2006, 11: 12-16.

[4] HongXia Jia, LiWan Li, W. S inghose. Consider boom elastic jib crane dynamics modeling and vibration analysis [J]. journal of vibration and impact, 2010, 14: 136-140 + 244.

[5] Lei Zhou. Based on the theory of beam gantry crane dynamics [D]. Wuhan university of technology, (2012).

[6] ChengZhong He. Study on Dynamic Properties of The Conveyor & Grab Crane Under Offloading Load [D]. Wuhan university of technology, (2010).
