Study on Failure Trend of L-Type Deflection Machine Structure on Basis of Static Strength Analysis

Abstract:

To ensure the safe use of L-type deflection machine for processing and manufacturing railway vehicles. This paper analyzes the use conditions of L-type deflection machine, and makes a contact nonlinear finite element analysis on various typical use conditions. The positions of parts subject to danger can be found out through the results of static strength analysis, which finds out the weaknesses and prejudges the failure trend of parts, and which provides guidance for prejudging the faults in actual production and can prevent occurrence of accidents.

• Periodical: Advanced Materials Research (Volumes 834-836)
• Pages: 1484-1487
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.834-836.1484
• Online since: October 2013
• Authors: Sheng Yong Cao, Ying Shi Sun, Liang Xuan
• Keywords: Contact Analysis, Failure Trend, L-Type Deflection Machine, Static Strength

References

[1] Hongyun Li, Shexu Zhao, Yan Sun. ANSYS 10. 0 Foundations and Engineering Applications [M]. Beijing: China Machine Press, (2008).

[2] Xinyu Zhang. Finite Element Static Strength Analysis of Ladle Revolving Platform Supporting Arm [J]. Mechanical Engineer, 2010. 10.

[3] Qingwu Wang, Fang Zuo, Renxi Hu, etc. ANSYS 10. 0 Advanced Mechanical Design Applications (Edition 2) [M]．Beijing: China Machine Press, 2006. 1.
