Research on Even-Loading Mechanism of Multi-Planetary Gear Transmission

Abstract:

Multi-planetary gear transmission is usually used in construction equipment, metallurgical machinery and wind-driven generator. Driving mechanism of heavy-duty equipment without even-loading system is badly loading, resulting in great impact force and severe vibration. To study characteristic of power dividing, multi-planetary gear transmission without any even-loading mechanism and that with flexible pin even-loading mechanism were simulated in commercial gear drive design software and dynamics analysis software. The simulation results are shown in this paper and conclusions are drawn useful for design and manufacture of heavy-duty multi-planetary gear transmission.

• Periodical: Advanced Materials Research (Volumes 834-836)
• Pages: 1476-1479
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.834-836.1476
• Online since: October 2013
• Authors: Kun Li Mao
• Keywords: Even-Loading Mechanism, Flexible Pin, Gearbox Design Software, Multi-Planetary Gear Transmission, Power Dividing

References

[1] Singh A: ASME Journal of Mechanical Design Vol. 127 (2005), p.469.

[2] Junhua Lu, Rupeng Zhu, Guanghu Jin: Chinese Journal of Mechanical Engineering Vol. 45 (2009), p.85 (in Chinese).

[3] Tao Zhang: Mechanical Science and Technology for Aerospace Engineering Vol. 27 (2008), p.1167 (in Chinese).

[4] Yuhang Wang, Zhangsheng Tong, Xiuying Wu, Fan Zhang, Yongpeng Li: Heavy Machinery Vol. S2 (2012), p.158 (in Chinese).

[5] Keping Tang: Journal of Mechanical Transmission Vol. 28 (2004), p.33 (in Chinese).

[6] Yue Liu, Ming Mao, Mingcheng Wang, Yanhui Shi: Manufacturing Automation Vol. 33 (2011), p.100 (in Chinese).

[7] Yanlin Tian, Jingliang He, Haolong Niu: Journal of Beijing Information Science and Technology University Vol. 26 (2011), p.80 (in Chinese).

[8] Kunli Mao, Jun He: Advanced Materials Research Vols. 562-564 (2012), p.979.

[9] Kunli Mao: Applied Mechanics and Materials Vols. 397-400 (2013), p.564.
