Controlling a Social Robot - Performing Nonverbal Communication through Facial Expressions

Abstract:

This paper focuses on our primary goal to achieve the emotional behaviour of the new version of the social robot Probo. The ability to enhance nonverbal communication with children is possible through facial expressions, eye-tracking and face-to-face contact. The new social robot has 21 degrees of freedom (DOF), grouped in five subsystems, named generically: eyes, ears, trunk, mouth and neck. The robotic head is actuated using only servo motors and all the components are manufactured using cheap, flexible and easy technologies. In order to get the social robot head able to express emotions, a Graphical User Interface (GUI) was developed. In this way facial expressions are created through sliders or push buttons. Additionally, we investigated the possibility of controlling the robot with an Arduino board. In this case, using pre-programmed or learned algorithms, the robot is getting a semiautonomous level, based on the usage of various sensors, being able to express six basic emotions: happiness, sadness, fear, anger, surprise and disgust. So, based on the feedback provided by the sensors, the robot can react accordingly, enhancing human-robot interaction (HRI).

• Periodical: Advanced Materials Research (Volume 837)
• Pages: 525-530
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.837.525
• Online since: November 2013
• Authors: Florentina Adăscălitei, Ioan Doroftei, Dirk Lefeber, Bram Vanderborght
• Keywords: Arduino, Facial Expression, GUI, HRI, Probo, Robot Control, Social Robot

References

[1] S.S., Ge, C., Wang, C.C., Hang, A facial expression imitation system in human robot interaction, In The 17th International Symposium on Robot and Human Interactive Communication, (2008).

DOI: 10.1109/roman.2008.4600668

[2] C.L., Breazeal, Designing Sociable Robots, MIT Press, Massachusetts, (2002).

[3] C. L. Breazeal, Robotic Life - Sociable Robots, http: /robotic. media. mit. edu/projects/ Leonard/ Leo-learning. html, (2005).

[4] S., Sosnowsky, A., Bittermann, K., Kuhnlenz, M., Buss, Design and Evaluation of Emotion-Display EDDIE, In Proceedings of the 2006 IEEE/RSJ International Conference on Intelligent Robots and Systems, 2006, pp.3113-3118.

DOI: 10.1109/iros.2006.282330

[5] A.J.N. Van Breemen, P. Res, and N. Eindhoven, Animation Engine for Believable Interactive User-interface Robots, In Proceedings of 2004 IEEE/RSJ International Conference on Intelligent Robots and Systems, volume 3, pp.2873-2878, (2004).

DOI: 10.1109/iros.2004.1389845

[6] H.S. Lee, J.W. Park, M.J. Chung, A Linear Affect - Expression Space Model and Control Points for Mascot-Type Facial Robots, IEEE Transactions on Robotics, 23(5): 863-873, (2007).

DOI: 10.1109/tro.2007.907477

[7] K. Goris, J. Saldien, B. Vanderborght, D. Lefeber, Mechanical design of the huggable robot Probo, International Journal of Humanoid Robotics. Volume 8, Issue 3 (2011) 481-511.

DOI: 10.1142/s0219843611002563

[8] J.A., Russell, Affective space is bipolar, Journal of Personality and Social Psychology 37(3), 1979, pp.345-356.

[9] P., Ekman, W.V., Friesen, P., Ellsworth, Does the face provide accurate information?, In P. Ekman (Ed. ), Emotion in the human face (2nd ed. ), Cambridge, UK: Cambridge University Press, 1982, pp.56-97.

DOI: 10.1016/b978-0-08-016643-8.50027-6

[10] R., Plutchik, Emotion, a psychoevolutionary synthesis, Ed. Harber&Row, (1980).

[11] L., Brethes, F., Lerasle, P., Danes, Data fusion for visual tracking dedicated to human-robot interaction, In Proceedings of the 2005 IEEE International Conference on Robotics and Automation, (Barcelona, Spain), 2005, p.2075-(2080).

DOI: 10.1109/robot.2005.1570419

[12] A., Mehrabian, A., Silent Messages. Belmont, CA: Wadsworth, ISBN 0-534-00910-7, (1971).

[13] K. Berns, T. Braum, Design Concept of a Human-like Robot Head, In Proceedings of 2005 IEEE-RAS 5th International Conference on Humanoid Robots, (2005), pages 32-37.

DOI: 10.1109/ichr.2005.1573541

[14] http: /www. mathworks. com/hardware-support/arduino-matlab. html.

[15] J., Saldien, K., Goris, B. Vanderborght, J., Vanderfaeillie, D., Lefeber, Expressing Emotions with the Social Robot Probo, Int J Soc Robot (2010) 2: 377-389, Springer.

DOI: 10.1007/s12369-010-0067-6
