Field Measurement and Analysis of Vibration Response in the Metro Shield Tunnel with Straight Joint

Abstract:

Appling the M8 as the monitor objects and choosing the single-round shield tunnel with or without the steel spring floating slab and the DOT shield tunnel with straight joint as the research objects, the vertical vibration response of the track bed and the standard block in different conditions was compared. The peak vibration acceleration of two measuring points and vibration response time of the standard block in the DOT is smaller compared with the DOT and the single-round shield tunnel when a single train is through the monitoring section. Vibration response time and intensity of the DOT structure is increasing with two trains intersection. Compared to the other two shield tunnels, structural vibration response of the single-round shield tunnel is significantly decreased by the isolation effect of steel spring floating slab. For the vibration acceleration of the track bed and the standard block in the three types of shield tunnels, spectrum range is 0Hz~150Hz, and peak acceleration is in the same frequency range, which is 35Hz~70Hz. Peak vibration acceleration of the track bed is greater than that of the standard block.

• Periodical: Advanced Materials Research (Volumes 838-841)
• Pages: 1363-1369
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.838-841.1363
• Online since: November 2013
• Authors: Ming Yu Li, Yuan Cheng Guo
• Keywords: Metro Shield Tunnel, Straight Joint, Vibration

References

[1] Bing Bai, Chunfeng Lee. Elastoplastic dynamic responses of close parallel metro tunnels to vibration loading. Rock and Soil Mechanics 2009; 30(1): 123-128 (in Chinese).

[2] Bin Cheng. Study on the settlement of shield tunnels due to Metro Train vibrating loads. D. Phil. thesis, Dept. of Geotechnics, Tongji University, 2003 (in Chinese).

[3] Zhenxing He, Wanming Zhai, Zhen Luo. Ground vibration caused by moving metro trains. Journal of Southwest Jiaotong University 2008; 43(2): 218-221 (in Chinese).

[4] Gengcai Hang. Study on displacement law under periodic load induced by train on the turbulent Soil. M. Phil. thesis, Dept. of Geotechnics, Tongji University, 2007 (in Chinese).

[5] Yuekui Shen. Study on the propagation Laws of Subway-induced vibration and isolation or reduction methods of building vibration. D. Phil. thesis, Dept. of Geotechnics, Tongji University, 2007 (in Chinese).

[6] Lianjin Tao, Xiaolin Lee, Xi Lu, Dingsheng Zhang. Study on attenuation law of ground motion induced by subway shock. World Earthquake Engineering 2003; 19(1): 84-87 (in Chinese).

[7] Yiqun Tang, Changqing Luan, Xi Zhang, Jianxiu Wang, Ping Yang. Numerical simulation of saturated soft clay deformation around tunnel under subway vibration loading. Chinese Journal of Underground Space and Engineering 2008; 4(1): 105-110 (in Chinese).

DOI: 10.1201/9780203879986.ch119

[8] Wei Tian. Dynamic response of tunnel and track structure subjected to metro load and vibration attenuating methods. M. Phil. thesis, Dept. of Geotechnics, Tongji University, 2007 (in Chinese).

[9] Zhiliang Wang. Research on deformation characteristics and structural properties for operating metro shield tunnel in Shanghai. D. Phil. thesis, Dept. of Geotechnics, Tongji University, 2010 (in Chinese).

[10] Weiping Xie, Honggang Shun. Fem analysis on wave propagation in soils induced by high speed train loads. Chinese Journal of Rock Mechanics and Engineering 2003; 22(7): 1181-1184 (in Chinese).

[11] Ling Xu. Research on longitudinal settlement of shield tunnel in soft soil. D. Phil. thesis, Dept. of Geotechnics, Tongji University, 2005 (in Chinese).

[12] Xi Zhang. The study on the Micro-structure and dynamic characteristic of soft clay around tunnel under the subway-included loading. D. Phil. thesis, Dept. of Geotechnics, Tongji University, 2007 (in Chinese).
