Acquisition of Capillary Pore Structure by X-Ray CT and Visualization of Flow by Numerical Analysis

Abstract:

In concrete, air, water, and ions are passed mainly through pores inside the material. The purpose of this study is to visualize a flow in pore of the cement paste by a model based on the measurement. In this study, X-ray CT images are used to ascertain the pore structure. Using the X-ray, a CT image of cement paste specimens with two kinds of water/cement ratios (W/C) and a three-dimensional image of the pore structure are represented using about 2 μm voxel mesh. The voxel mesh is used as an analysis mesh in voxel finite element method (FEM) and seepage analysis. A typical pore model was taken out of the three-dimensional image of pore structure obtained by X-ray CT scanning and the fluid analysis was carried out by using the typical pore model.

• Periodical: Advanced Materials Research (Volume 845)
• Pages: 163-167
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.845.163
• Online since: December 2013
• Authors: Maho Shibata, Shinichiro Okazaki, Isao Ujike*
• Keywords: Cement Paste, Homogenization Seepage Analysis, Porosity, Voxel Finite Element Method, X-Ray CT

References

[1] A. Masuda M.A.B. Promentilla,T. Sugiyama: Observation of the microstructure change by X‐rays CT with the materials age progress of the cement paste, Proceedings of the Japan Concrete Institute, 2010, Vol. 32, No. 1 pp.539-544.

[2] N. Hitomi,T. Takeda, Nyuunoya and K. Iriya: Calculation of Calcium Diffusion Coefficient of Cement Hardenings Using Minute Pore Data, Report of Ohbayashi Corporation Technical Research Institute, 2009, No. 73pp. 1-10.

[3] K. Terada,N. Kikuchi, Introduction to the Mathematical Homogenization Method, Maruzen Company, (2003).
