Design of Induction Heating Power Based on the Power Adjusting Technique and the Frequency Tracing

Abstract:

The ultrahigh frequency (more than 1MHz) of the HF Induction Heater need to be reached for surface-heat-processing of tiny mental components, which is not available by the traditional HF Induction Heater. To satisfy these requirements, by using the high-speed field effective transistor (FET) and high-speed phase locked loops (PLL: MM74HC4046), the frequency of inverts for induction heater and the power can arrive at more than 1MHz and 5.5kW respectively at the same time. Additionally, it achieves the power adjusting technique and the frequency tracing. The experimental shows that this design can both achieve the high frequency and efficiency, and meet the requirement of the surface-heating-process of the tiny components.

• Periodical: Advanced Materials Research (Volumes 846-847)
• Pages: 13-17
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.846-847.13
• Online since: November 2013
• Authors: Yao Chen Wang*, Hui Wei He, Dong Chen Yan, Jin Hui Xiong
• Keywords: Frequency Tracing, Induction Heating, Phase Locked Loop Control, Power Adjusting Technique

References

[1] Stanley Zinn, S. L. Semiatin. , Elements of Induction Heating: Design, Control, and Applications ASM International Press, (1988).

[2] Lina C. , GP Series Vacuum Tube Steel Pipe Welding Device, Baoding ZSHC Eletrical Press, (2009).

[3] Chen S. , Zhaolin W. , 20Kw/300KHz HF Induction Heating Power Supply Power , Electronics Press , 30.

[2] pp.10-13 (1996).

[4] Jinfei S., Lei W. Jing H., 1Kw/2MHz Super HF Induction Heating Power Supply Power, Power Electronics Press , 36.

[6] pp.13-15 (2002).

[5] Tianming P., Modern induction heating equipment , Metallurgical Industry Press, (1996).

[6] Jing Z., Bojin Q., Wei Z., Resonance Frequency Auto-tracing Technology Based on PI Control for IGBT Induction Heating Power Source, Power Electronics Press, 37.

[2] pp.12-14 (2003).
